1. Ensure that the instrument's power switch is off, that is, the instrument is in
2. Insert the separately purchased RS–232 interface card into the card slot on
3. Connect the instrument to the computer via an RS–232 cable. After the con-
4. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
5. Rotate the knob or press the Up/Down key to select I/O and press [Enter].
6. Press the Left/Right key to select RS232 and press [Enter].
7. Set the relevant communication parameters in turn, and press [Enter].
RS-232 Troubleshooting
If you meet some problems when communicating with PC by RS-232 interface,
please check the following items:
•
•
•
Power Off state.
the rear panel of the instrument.
nection is successful, turn on the power switch of the instrument.
ter the system menu.
The RS–232 interface parameters are as follows.
Name Description
Baud rate Select the baud rate from the following options: 4800/9600/
19200/38400/57600/115200
Data Bit The options are: 5/6/7/8
Parity bit The options are: N (no parity), O (odd parity), E (even
parity).
Stop bit The options are: 1/2
Check that whether the baud rate of the computer and instrument are the
same;
Make sure the correct cable and adapter are connected. Note that internal
wiring may not be correct even if the cable has a suitable plug;
The cable must be connected to the correct serial ports (COM1, COM2, etc)
of PC.
