1.2 Front-Panel Overview

The detailed descriptions of IT-M series front panel are shown as below.
No.
1
2
3
Support On/Off delay
Automatic detection of power grid state to realize reliable grid connection
Parallel up to 16 units
Independent control of multi-channels,implement synchronization or
proportional tracking
sense abnormal protection
Temperature measurement function,over temperature protection
Anti-reverse protection function through optional accessories
Power-off protection
Five optional cards, supporting RS232, CAN, LAN, GPIB, USB_TMC, USB_
VCP, RS485, analog and IO communication
High-speed measurement, keep 10 times / s update rate even connecting
16 stand-alone units
Name
[Shift] key
[Link](Local)
Key
Power On/Off
switch
Copyright © Itech Electronic Co., Ltd.
Description
Composite key, combined with other keys to realize
functions as marked above keys.
•
Turn the synchronized operation feature on or
off. When lit, indicates that the instrument is in
synchronous.
•
In remote control, press [Shift]+[Link] keys to
switch the instrument to local control mode.
Turns instrument on or off.
Quick Reference
