System features:
•
•
•
•
•
•
•
•
•
•
•
•

1.2 Front-Panel Overview

The detailed descriptions of IT-M series front panel are shown as below.
Bidirectional energy flow between DUT and grid
8 operating mode: CC/CV/CP/CR/CC+CV/CV+CR/CR+CC/CC+CV+CP
+CR
Programmable current rise and fall time
Battery discharge test
Support Von function
Various protection such as OCP,OPP,UVP
One button switch between source and sink on panel
Bidirectional energy flow and support battery simulation
Support On/Off delay
Automatic detection of power grid state to realize reliable grid connection
Parallel up to 16 units
Independent control of multi-channels,implement synchronization or
proportional tracking
sense abnormal protection
Temperature measurement function,over temperature protection
Anti-reverse protection function through optional accessories
Power-off protection
Five optional cards, supporting RS232, CAN, LAN, GPIB, USB_TMC, USB_
VCP, RS485, analog and IO communication
High-speed measurement, keep 10 times / s update rate even connecting
16 stand-alone units
