Run Battery Simulation File
After the battery simulation file is edited, you can select a file to run directly.
After executing Run, you also need to set the initial state of charge (SOC),
which is the ratio of the present battery's capacity divided by the full voltage
capacity.
•
•
Run a user-defined battery simulation file
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
2. Use knob or Up/Down key to select 5.Battery Emulator: Off and press
[Enter].
The interface is displayed as follows:
FUNCTION BEMULATOR
User-define
3. Enter the User-define→Open, and set the Recall File to select the file
to run, press [Enter].
4. Press the Left/Right key to select Run and press [Enter].
5. Set the Initial Value and press [Enter].
The instrument will enter the battery simulation test mode and wait for
the function to be triggered.
6. Turn on the [On/Off].
7. Based on the selected trigger method, perform the trigger operation.
The trigger method of the battery simulation is consistent with the trig-
ger method of the List function, that is, the List trigger source is also
effective for the Battery Emulator.
Run battery simulation curve file
1. Save the edited battery simulation curve file to the root directory of the
USB flash disc.
2. Insert the USB flash disc into the USB interface on the front panel of the
instrument.
3. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
4. Use knob or Up/Down key to select 5.Battery Emulator: Off and press
[Enter].
