1.2 Front-Panel Overview

The front panel of this series of instruments is shown in the figure below.
Model
IT-M3904D-300-40
IT-M3906D-300-60
IT-M3912D-300-120
IT-M3902D-500-12
IT-M3904D-500-24
500V
IT-M3906D-500-36
IT-M3912D-500-72
IT-M3902D-800-8
IT-M3904D-800-16
800V
IT-M3906D-800-24
IT-M3912D-800-48
IT-M3906D-1500-12
1500V
IT-M3912D-1500-24
Naming rules for each series of model are as follows: IT-M39XXD-YYY-ZZZ,
wherein, XX means rated power; YYY means rated voltage; and ZZZ means
rated current.
The above model is permanently connected, Equipment Class I, Pollution De-
gree 2, Installation Category II.
Mode of operation: Continuous.
Copyright © Itech Electronic Co., Ltd.
Current Power
40A 4kW
60A 6kW
120A 12kW
12A 2kW
24A 4kW
36A 6kW
72A 12kW
8A 2kW
16A 4kW
24A 6kW
48A 12kW
12A 6kW
24A 12kW
