ITech IT6000C Series User Manual page 14

•
During the test, the instrument can record specific data type (such as voltage
value) and save it in the USB memory device;
•
The front panel can be inserted with the USB memory device to support
such functions as system file upgrade, import/export of List files and data
record;
•
Strong Digital I/O Function: In addition to general digital signal I/O functions,
it can also be customized by supporting the wiring through different pins to
meet different special needs through different pin wirings;
•
Select CC loop priority or CV loop priority. If voltage and current parameters
are to be changed frequently during test, the user can directly set related pa-
rameters through [V-set] and [I-set] on the front panel, which is very
convenient;
•
Built-in voltage curves comply with multiple automotive standards for quick
user recall.
•
Built-in maximum power point tracking (MPPT) mechanism to provide solar
photovoltaic curve simulation.
•
High visible vacuum fluorescent display (VFD)
•
Support optical fiber communication, which is applicable for loop control be-
tween units under parallel mode.
•
Built-in USB/CAN/LAN communication interface
•
Optional GPIB/RS–232 communication interface
•
Optional external analog interface, and share an interface position with RS-
232.
•
Strong trigger system;
•
Enable a true seamless switch between positive current and negative cur-
rent while avoiding overshoot current and overshoot voltage;
•
When the Sense function is turned on, it can ensure that the DUT is safe in
case of reverse connection or open circuit of the Sense line.
The models included in the IT6000C series are as follows:
Voltage Model
Level
IT6005C-80-150
IT6010C-80-300
80V
IT6015C-80-450
IT6015C-80-450S
Copyright © Itech Electronic Co., Ltd.
Quick Reference
Current Power
150A 5KW
300A 10KW
450A 15KW
450A 15KW
2
