Voltage
Level
1.2 Front-Panel Overview
The front panel of this series of instruments is shown in the figure below.
1U Model
1 Power On/Off switch
2 USB storage device connec-
tion port
3 Vacuum fluorescent display
(VFD)
4 Function and composite keys
Model
IT-M3904D-300-40
IT-M3906D-300-60
IT-M3912D-300-120
IT-M3902D-500-12
IT-M3904D-500-24
500V
IT-M3906D-500-36
IT-M3912D-500-72
IT-M3902D-800-8
IT-M3904D-800-16
800V
IT-M3906D-800-24
IT-M3912D-800-48
1500V
IT-M3906D-1500-12
Naming rules for each series of model are as follows: IT-M39XXD-YYY-ZZZ,
wherein, XX means rated power; YYY means rated voltage; and ZZZ means
rated current.
Copyright © Itech Electronic Co., Ltd.
Current
40A
60A
120A
12A
24A
36A
72A
8A
16A
24A
48A
12A
5 Numeric and composite keys
6 Push-on knob
7 Left, and right cursor navigation keys
Quick Reference
Power
Height
4KW
1U
6KW
1U
12KW
2U
2KW
1U
4KW
1U
6KW
1U
12KW
2U
2KW
1U
4KW
1U
6KW
1U
12KW
2U
6KW
1U
3
