The detailed parameter description is as below.
Ext-Program External analog function menu
On / Off
Ch1
Ch2
Ch3
•
CV priority: The actual output voltage Vs will be adjusted according to the
parameter setting of Ch1 and the input voltage of the corresponding pin.
And, the current upper limit I+ will be adjusted according to the parameter
setting of Ch2 and the input voltage of the corresponding pin, the current
lower limit I- will be adjusted according to the parameter setting of Ch3 and
the input voltage of the corresponding pin.
•
CC priority: The actual current voltage Is will be adjusted according to the
parameter setting of Ch1 and the input voltage of the corresponding pin.
And, the voltage upper limit Vh will be adjusted according to the parameter
setting of Ch2 and the input voltage of the corresponding pin, the voltage
lower limit Vl will be adjusted according to the parameter setting of Ch3 and
the input voltage of the corresponding pin.
Copyright © Itech Electronic Co., Ltd.
Function switch:
•
On: Turns on the external analog function.
In this state, the channel parameters cannot
be set.
•
Off: Turns off the external analog function.
In this state, the channel parameters can be
set.
Set the parameters of channel 1 (programmed
channel).
Mx Indicates the slope factor of channel 1.
Mb Indicates the offset of channel 1.
Set the parameters of channel 2 (upper limit
channel).
Mx Indicates the slope factor of channel 2.
Mb Indicates the offset of channel 2.
Set the parameters of channel 3 (lower limit
channel).
Mx Indicates the slope factor of channel 3.
Mb Indicates the offset of channel 3.
