  • Page 1 PCIe-ACC100 (a.k.a. PCIe-A100) FEC Accelerator Based On Intel® vRAN Dedicated Accelerator ACC100 User’s Manual Manual Rev.: Rev. 1.2 Revision Date: October 20, 2022 Part No.: 50M-00045-1020...

  • Page 2: Preface

    PCIe-ACC100 Preface Copyright © 2022 ADLINK Technology, Inc. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 3 PCIe-ACC100 Conventions Information to prevent minor physical injury, component damage, data loss, and/or program corruption when trying to complete a task. Informations destinées à prévenir les blessures corporelles mineures, les dommages aux composants, la perte de données et/ou la corruption de programme lors de l'exécution d'une tâche.

  • Page 4: Table Of Contents

    Block Diagram.......................... 6 Mechanical Overview ....................... 7 1.2.1 PCIe-ACC100 - Half Height.......................7 1.2.2 PCIe-ACC100 - Full Height .......................8 2 Specifications ........................9 PCIe-ACC100 Specifications ....................9 3 Testing the Module ......................10 Important Safety Instructions.................... 12 Consignes de Sécurité Importantes ................. 14...

  • Page 5: Overview

    1 Overview 1.1 Introduction The ADLINK PCIe-ACC100 (also knows as PCIe-A100) is a single-slot eASIC FEC accelerator server adapter based on the Intel® vRAN Accelerator ACC100 adapter. The PCIe-ACC100 can be deployed in various Xeon-based COTS servers ranging from dual- socket Xeon-SP rackmount implementations, single socket Xeon-SP edge servers through to low-core-count (LCC) based Xeon-D servers.

  • Page 6: Block Diagram

    PCIe-ACC100 1.1 Block Diagram JTAG Intel® vRAN DDR HARQ Buffer + ECC 2667 Mb/s D Accelerator ACC100 Adapter PCIe x16 x8 (ECC) DDR4 1GB x8 Gen3 DDR4 (Mount Bryce) DDR4 4GB x64 DDR4 I2C Master Buffer 540BAA333M330CBGR DDR4_REFCLK 333.33MHz TCA9406...

  • Page 7: Mechanical Overview

    PCIe-ACC100 1.2 Mechanical Overview 1.2.1 PCIe-ACC100 - Half Height Dimensions: mm (169.3) (22.0)

  • Page 8: Pcie-Acc100 - Full Height

    PCIe-ACC100 1.2.2 PCIe-ACC100 - Full Height Dimensions: mm (21.6) (169.4)

  • Page 9: Specifications

    PCIe-ACC100 2 Specifications 2.1 PCIe-ACC100 Specifications Performance 5G throughput: 21Gbps encode, 8Gbps decode 4G throughput: 8.4Gbps encode, 2.1Gbps decode Software and Interface via DPDK BBDev Cloud Support Clould native, VM and bare metal, SRIOV/Vt-d Interface PCIe x16 Gen3 interface to host...

  • Page 10: Testing The Module

    PCIe-ACC100 3 Testing the Module 1. OS: Install an operating system such as Ubuntu 20.04. Login and switch to user “root” (su root). Make sure this server is connected to Internet. 2. Copy files: Copy the file test-bbdev.tar.gz to /home and unpack it.
  • Page 11 PCIe-ACC100 5. Test the bbdev: ./test-bbdev.sh The test is OK if you see the “Tests Passed” count.

  • Page 12: Important Safety Instructions

    PCIe-ACC100 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. 1. Read these safety instructions carefully. 2. Keep this user’s manual for future reference.
  • Page 13 PCIe-ACC100 9. This equipment is not suitable for use in locations where children are likely to be present. 10. Equipment must be serviced by authorized technicians when: • The power cord or plug is damaged; • Liquid has penetrated the equipment;...

  • Page 14: Consignes De Sécurité Importantes

    PCIe-ACC100 Consignes de Sécurité Importantes Pour assurer la sécurité de l’utilisateur, veuillez lire et suivre toutes les directives, ainsi que les AVERTISSEMENTS, MISES EN GARDE et REMARQUES de ce manuel et indiqués sur l’équipement associé avant de manipuler ou utiliser l’équipement.
  • Page 15 PCIe-ACC100 8. Une pile au lithium peut être installée pour assurer l’alimentation de secours ou d’urgence en continu. Risque d'explosion si la batterie est remplacée par une batterie d'un type incorrect. Jetez les piles usagées conformément aux instructions du fabricant.

  • Page 16: Getting Service

    6450 Via Del Oro, San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 上海市浦东新区张江高科技园区芳春路 300 号 (201203) Address: 300 Fang Chun Rd., Zhangjiang Hi-Tech Park, Pudong New Area Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com...
