Export Files; List Files; Software Setup - Micromeritics GEMINI VII Operator's Manual

E F
XPORT ILES
File > Export
Exported Data Example on page C - 1
Provides the option to print the contents of one or more sample or parameter files to either the
screen, a printer, or a file. Data can be exported as a .PDF, .TXT, .XML, or .XLS file format. The
type of data to include or exclude can be selected during the export process. When exported to a
file, the data can be imported into other applications that read these file formats.
L F
IST ILES
File > List
Provides the option to create a list of sample file information —such as file name, date, time the
file was created or last edited, file identification, and file status.
Select one or more files from the file selector, click List, then provide the file destination.
Example of File List
S S
OFTWARE ETUP
If the computer is to be connected to a network, a second Ethernet port on the
computer must be used for that purpose.
The Setup program is located on the installation media and is used to reinstall the software and
make analyzer changes — such as adding, moving, or removing a unit, etc.
If the IP address needs to be changed on the computer connected to the analyzer,
refer to the computer's operating system manual or the internet for instructions. The
IP address for the computer and the IP address specified in the setup program must
match. The IP address must be 192.168.77.100.
Gemini VII Operator Manual
239-42828-01 (Rev H ) — May 2021

Export Files

2 - 21
