-P R
T LOT EPORT
The t-Plot calculation allows quantitative analysis of the area and total volume ascribed to
micropores. Matrix area (the area external to micropores) is directly determined and often proves
to be a valuable way of characterizing complex mixed materials.

t-Plot Report

Field or Button
Fitted thickness range
[text box]
Pressures [button]
Gemini VII Operator Manual
239-42828-01 (Rev H ) — May 2021
Description
Enter the minimum and maximum thicknesses (in angstroms or nano-
meters) to include in the thickness curve. Go to Options > Units to
specify default units.
Use to select a pressure range for report calculations and points for
exclusion from calculations.
Calculation pressure range. Enter the minimum and maximum
pressures to be used in the pressure table.To exclude a point from
the calculations used to generate the report, select Exclude.
Exclude All. Select to exclude all pressure points in the table.
Include All. Select to include all pressure points in the table.
t-Plot Report
7 - 45
