Performance Verification
.
MG3700
Vector Signal
Generator
250kHz-6GHz
(to back panel)
Figure 2-26. Mobile WiMAX Signal Analyzer – Test Setup
Mobile WiMAX Channel Power Accuracy Tests (Option 66)
Procedure:
1. Connect the MA2482D Power Sensor to the power meter and zero the sensor.
2. Set the Power Meter Measurement MODE to "True RMS", set Averaging MODE to "Moving", and set
Averaging NUMBER to "256".
3. Set the calibration factor frequency of the power sensor to 2600.5 MHz.
4. Connect all of the test equipment as shown in
Models MS2723B and MS2724B MM
ML2438A Power Meter
MG3700A
Function
Ethernet
10 MHz Reference
PN: 10580-00165 Rev. D
2-11 Mobile WiMAX Signal Analyzer Verification
Cursor/Edit
34NN50A
Adapter
RF Output
Control Input
Modulation Input
15NN50-1.5B
Figure 2-26
Sensor
Attenuator
Power
Splitter 1870A
Attenuator
34NN50A
Adapter
MS2724B
10 dB
10 dB
2-71
