Anritsu Spectrum Master MS2723B Maintenance Manual page 25

Performance Verification
Figure 2-5. 2400 MHz TOI Verification - Characterization – Component Characterization Setup
Procedure:
1. Connect the equipment as shown in
Characterization – Component Characterization Setup" on page
RF combiner (the normal RF outputs will become inputs, and the normal input will become the
RF output).
2. Set the MG3692x Synthesized Signal Generator to 2399.951 MHz CW, and set the Agilent 8648D Signal
Generator to 2400.051 MHz.
3. Set the Agilent 8648D Signal Generator RF to OFF ("RF OFF" appears on the right side of the display).
4. On the ML2438A power meter, zero the sensor and set the calibration factor to 2.4 GHz.
Models MS2723B and MS2724B MM
Adapter
34NN50A
MS2724B
2 dB 6 dB 20 dB
Attenuators
MG3692A
Figure 2-5, "2400 MHz TOI Verification -
PN: 10580-00165 Rev. D
2-2 Spectrum Analyzer Function Verification
ML2438A Power Meter
Sensor
20 dB 6 dB 2 dB
Power Attenuators
Splitter
1870A
Agilent 8648D
To
Rear
10 MHz Reference
2-11. The splitter will be used as an
7 8 9
6
4 5
1 2 3
0 .
+/-
2-11
