Replaceable Parts - Anritsu Spectrum Master MS2723B Maintenance Manual

General Information
1-4

Replaceable Parts

Table 1-3. List of Replaceable Parts
Part Number
ND67986
ND68847
ND71309
ND67987
ND69102
ND71310
ND66821
3-15-118
3-15-154
61368
3-66549-3
65729
ND69114
ND69107
66148
66149
61379-1
633-44
633-75
510-87
3-513-64
ND64383
3-633-26
40-168-R
3-2000-1567
3-71027-3
61362
61363-1
61361
61378-1
3-71030-3
790-625
3-410-101
61360-2
a.When ordering the Main/Spectrum Analyzer PCB Assembly, in order to ensure installation of correct options, all options that
are installed on the instrument must be declared on the order. The options are listed on a label on the top of the MS272xB and
are shown in the System / Status display.
Models MS2723B and MS2724B MM
Description
MS2723B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
a
S/N < 0815110
MS2723B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
S/N > 0815109 and < 1003000
MS2723B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
a
S/N > 1002999
MS2724B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
a
S/N < 0815110
MS2724B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
S/N > 0815109 and < 1003000
MS2724B Main/Spec Analyzer PCB Assembly, with Option 9 & 31 with
a
S/N > 1002999
MS272xB Demodulation PCB (Option 9)
LCD Display for Units with S/N < 1003000
LCD Display for Units with S/N > 1002999
Clear Plastic LCD Protector
LCD Backlight Inverter PCB for Units with 3-15-118 LCD
Soft Carrying Case
Case Top (excludes model ID Label and keypad items)
Case Bottom (includes tilt bail)
Model MS2723B ID Label
Model MS2724B ID Label
Battery Door
Li-ion Battery Pack (Standard 6.3 Ah)
Li-ion Battery Pack (Optional High Capacity 7.5 Ah)
RF Adapter SMA(f) plug to N(f) jack
N Connector
Fan Assembly
3V RTC Battery
AC to DC Power Converter
Internal Compact Flash Card (512 MB)
Main Keypad PCB
Main Keypad
Main Keyboard Bezel
Mode keys Keypad
Mode key Bezel
Mode keypad PCB
Speaker
Encoder (excluding knob)
Knob (excluding encoder)
PN: 10580-00165 Rev. D
a
a
1-4 Replaceable Parts
1-5
