Performance Verification
26. On the power meter, press the Sensor key, the Cal Factor soft key, and then the Freq soft key. Use the
keypad to enter 1800 MHz as the input signal frequency, which sets the power meter to the proper power
sensor calibration factor. Press the System key to display the power reading.
27. Adjust the level of the MG3700A so that the power meter reads –10 dBm ± 0.2 dB. Record the adjusted
power reading into the "Adjusted Output Power" row of
ALL Pattern (GSM)" on page
28. On the MS2723B or MS2724B, set the Center Freq to 1800 MHz. Then wait 15 seconds to allow the
MS2723B or MS2724B to update its measured results.
29. For MS2723B or MS2724B with Option 40 (GSM/GPRS/EDGE RF Measurements), record the measured
value into the "Displayed Burst Power" row of
value from the "Adjusted Output Power" reading that was obtained in Step 27. Then record the
"Calculated Burst Power Error" (in units of watt) and the displayed value of Frequency Error into
Table A-50.
30. For MS2723B or MS2724B with Option 41 (GSM/GPRS/EDGE Demodulator), record the displayed Phase
Err RMS (deg) into
31. Verify that the measured values in Step
32. On the MG3700A, change the selected pattern to "GsmBurst_1slot".
33. Adjust the level of the MG3700A so that the power meter reads –50 dBm ± 0.2 dB. Record the adjusted
power reading into the "Adjusted Output Power" row of
Pattern (GSM)" on page
measured results.
34. For MS2723B or MS2724B with Option 40 (GSM/GPRS/EDGE RF Measurements), record the measured
value into the "Displayed Burst Power" row of
value from the "Adjusted Output Power" reading that was obtained in Step 33. Then record the
"Calculated Burst Power Error" (in units of watt) and the displayed value of Frequency Error into
Table A-51.
35. For MS2723B or MS2724B with Option 41 (GSM/GPRS/EDGE Demodulator), record the displayed Phase
Err RMS (deg) into
36. Verify that the measured values in Step

EDGE Burst Power, Frequency Error and Residual Error Tests

Test Procedure:
1. Verify that the equipment settings are unchanged from the previous test.
2. On the MG3700A, change the selected pattern to "DL_MCS-9_1SLOT".
3. Adjust the level of the MG3700A so that the power meter reads –50 dBm ± 0.2 dB. Record the adjusted
power reading into the "Adjusted Output Power" row of
DL_MCS-9_1SLOT Pattern (EDGE)" on page
MS2724B to update its measured results.
4. For MS2723B or MS2724B with Option 40 (GSM/GPRS/EDGE RF Measurements), record the measured
value into the "Displayed Burst Power" row of
value from the "Adjusted Output Power" reading that was obtained in Step 3. Then record the
"Calculated Burst Power Error" (in units of watt) and the displayed value of Frequency Error into
Table A-52.
5. For MS2723B or MS2724B with Option 41 (GSM/GPRS/EDGE Demodulator), record the displayed
EVM(rms) into Table A-60, "At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)"
on page A-25.
6. Verify that the measured values in Step
7. On the MG3700A, change the selected pattern to "DL_MCS-9_4SLOT".
Models MS2723B and MS2724B MM
A-22.
Table A-58, "At 1800 MHz, –50 dBm Level, TCH ALL Pattern (GSM)" on page
29
A-22. Then wait 15 seconds to allow the MS2723B or MS2724B to update its
Table A-59, "At 1800 MHz, –10 dBm Level, TCH Pattern (GSM)" on page
34
4
PN: 10580-00165 Rev. D
2-5 GSM/GPRS/EDGE Signal Analyzer Option Verification
Table A-50, "At 1800 MHz, –10 dBm Level, TCH
Table A-50, then subtract the "Displayed Burst Power"
or Step 30 or both are within specifications.
Table A-51, "At 1800 MHz, –50 dBm Level, TCH
Table A-51, then subtract the "Displayed Burst Power"
or Step 35 or both are within specifications.
Table A-52, "At 1800 MHz, –50 dBm Level,
A-23. Then wait 15 seconds to allow the MS2723B or
Table A-52, then subtract the "Displayed Burst Power"
and Step 5 are within specifications.
A-24.
A-24.
2-39
