2-2 Spectrum Analyzer Function Verification
to rear panel
connector
Figure 2-15. 9 kHz to 100 kHz Amplitude Accuracy Verification – Test Setup
Procedure:
1. Set the MS2723B or MS2724B to Spectrum Analyzer mode and then preset the instrument.
2. Press the BW soft key. Then set the RBW to 1 kHz, and set the VBW to 10 Hz.
3. Press the Span soft key, and set span to 10 kHz.
4. Press the Amplitude soft key. Then set the Reference Level to –20 dBm, and set the Atten Lvl to 0 dB.
5. Connect the MS2723B or MS2724B to the test setup as shown in
6. Set the MG3692x frequency to 9.5 kHz. Do not adjust the output power.
7. On the MS2723B or MS2724B, press the Freq soft key and press the Center Freq soft key.
8. Enter 9.5 kHz.
9. Press the Marker key and press the Peak Search soft key.
10. Record the Marker 1 amplitude reading (in units of dBm) into
Accuracy Verification" on page
11. Subtract the P
in
column in Table
2-30
ML2438A Power Meter
MG369XA Source
10 MHz Reference
A-20.
value from the Marker 1 reading, and record the result (in units of dBm) into the Error
A-45.
PN: 10580-00165 Rev. D
Adapter
15NNF50-1.5B
Ext Ref In
MS2724B
Figure 2-15.
Table A-45, "9 kHz to 100 kHz Amplitude
Models MS2723B and MS2724B MM
Performance Verification
Sensor A
10 dB
Attenuator
1870A
Power Splitter
10 dB
Attenuator
Adapter
