Anritsu Spectrum Master MS2723B Maintenance Manual page 118

Amplitude Accuracy Across Frequency Verification (continued)
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Amplitude Accuracy Across Frequency Verification (continued)
10.1 MHz, 50 MHz, 100 MHz, 500 MHz, 1000 MHz, 2000 MHz, 3000 MHz, 4000 MHz
Table A-23. Verification at 100 MHz, Specification = ± 1.3 dBm
Input Power
–30 dBm
–30 dBm
–30 dBm
–30 dBm
–2 dBm
–2 dBm
–2 dBm
–2 dBm
10.1 MHz, 50 MHz, 100 MHz, 500 MHz, 1000 MHz, 2000 MHz, 3000 MHz, 4000 MHz
Table A-24. Verification at 500 MHz, Specification = ± 1.3 dBm
Input Power
–30 dBm
–30 dBm
–30 dBm
–30 dBm
–2 dBm
–2 dBm
–2 dBm
–2 dBm
A-10
Atten Lvl
0 dB
5 dB
10 dB
20 dB
30 dB
40 dB
50 dB
60 dB
Atten Lvl
0 dB
5 dB
10 dB
20 dB
30 dB
40 dB
50 dB
60 dB
PN: 10580-00165 Rev. D
Marker 1 Reading
Marker 1 Reading
Models MS2723B and MS2724B MM
Test Records
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
