Test Records
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Option 62 EV-DO RF Measurements
Table A-87. At 870.03 MHz, –50 dBm Level, 921.6 kps 8-PSK Modulation
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Table A-88. At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Table A-89. At 1930.05 MHz, –50 dBm Level, 2457.6 kps 16-QAM Modulation
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Models MS2723B and MS2724B MM
Measured Value
Measured Value
Measured Value
PN: 10580-00165 Rev. D
Option 62 EV-DO RF Measurements
Specification
dBm –50 dBm ± 0.2 dB
dBm –50 dBm ± 0.2 dB
dB
Specification
dBm 0 dBm ± 0.2 dB
dBm 0 dBm ± 0.2 dB
dB
Specification
dBm –50 dBm ± 0.2 dB
dBm –50 dBm ± 0.2 dB
dB
±1.5 dB
±1.5 dB
±1.5 dB
