Anritsu Spectrum Master MS2723B Maintenance Manual page 143

Test Records
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Option 63 EV-DO Demodulator
Table A-92. At 870.03 MHz, –50 dBm Level, 921.6 kps 8-PSK Modulation
Frequency Error
Rho Pilot
Tau
Table A-93. At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Frequency Error
Rho Pilot
Tau
Table A-94. At 1930.05 MHz, –50 dBm Level, 2457.6 kps 16-QAM Modulation
Frequency Error
Rho Pilot
Tau
Table A-95. At 1930.05 MHz, –50 dBm Level, Idle Slot
Frequency Error
Rho Pilot
Tau
Table A-96. At 870.03 MHz, –10 dBm Level, Idle Slot
Frequency Error
Rho Pilot
Tau
Models MS2723B and MS2724B MM
Measured Value
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00165 Rev. D
Option 63 EV-DO Demodulator
Specification
Hz
0.99 ≤ x ≤ 1
us
Specification
Hz
0.99 ≤ x ≤ 1
us
Specification
Hz
0.99 ≤ x ≤ 1
us
Specification
Hz
0.99 ≤ x ≤ 1
us
Specification
Hz
0.99 ≤ x ≤ 1
us
±20 Hz
±1 us
±20 Hz
±1 us
±20 Hz
±1 us
±20 Hz
±1 us
±20 Hz
±1 us
A-35
