Performance Verification
MG3700A
MG3700
Vector Signal
Generator
250kHz-6GHz
(to back panel)
10 MHz Reference
Figure 2-18. GSM/GPRS/EDGE – Test Setup
Set up Procedure:
1. Connect the equipment as shown in
2. Calibrate the power sensor prior to connecting to the power splitter.
3. On the power meter, press the Sensor key, the Cal Factor soft key, and then the Freq soft key. Use the
keypad to enter 850 MHz as the input signal frequency, which sets the power meter to the proper power
sensor calibration factor. Press the System key to display the power reading.
4. Set the MS2723B or MS2724B mode to GSM/GPRS/EDGE Signal Analyzer. Preset the instrument.
Models MS2723B and MS2724B MM
2-5 GSM/GPRS/EDGE Signal Analyzer Option Verification
ML2438A Power Meter
Cursor/Edit
Function
Ethernet
Control Input
Modulation Input
To Ext Ref In
MS2724B
Figure
2-18.
PN: 10580-00165 Rev. D
15NNF50-1.5B
RF Output
Adapter
MA2482D
Power Sensor
Power
Splitter 1870A
N(m) to N(m)
Adapter
2-37
