2-2 Spectrum Analyzer Function Verification
Spectrum Analyzer Second Harmonic Distortion
This test verifies the second harmonic distortion of the Spectrum Analyzer in Spectrum Master Models
MS2723B and MS2724B.
Required Equipment:
• Anritsu MG3692x Synthesized Signal Generator
• Frequency Reference Symmetricom Rubisource T&M
• Adapter, Anritsu Model 34NN50A
• Spectrum Master: MS2723B or MS2724B
• Lowpass Filter, Anritsu Part Number 1030-96 (RLC Electronics)
(to back panel)
Figure 2-4.
Spectrum Analyzer Second Harmonic Distortion – Test Setup
2-8
MG3692X
10 MHz Reference
PN: 10580-00165 Rev. D
To Ext Ref In
Performance Verification
Low Pass
Filter
MS2724B
Models MS2723B and MS2724B MM
