Anritsu Spectrum Master MS2723B Maintenance Manual page 133

Test Records
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Option 41 GSM/GPRS/EDGE Demodulator (continued)
Table A-60. At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)
EVM RMS
Table A-61. At 1800 MHz, –10 dBm Level, DL_MCS-9_4SLOT Pattern (EDGE)
EVM RMS
Table A-62. At 850 MHz, –50 dBm Level, DL_MCS-9_4SLOT Pattern (EDGE)
EVM RMS
Table A-63. At 850 MHz, –10 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)
EVM RMS
Models MS2723B and MS2724B MM
Option 41 GSM/GPRS/EDGE Demodulator (continued)
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00165 Rev. D
Specification
% ± 2.5%
Specification
± 2.5%
%
Specification
± 2.5%
%
Specification
± 2.5%
%
A-25
