Performance Verification
6. For MS2723B or MS2724B with Option 62 (EV-DO RF Measurements), subtract the "MS272xB Reading"
of displayed Channel Power value from the "Power Meter Reading" in Step 3. Then record the
"Calculated Channel Power Error" into
7. For MS2723B or MS2724B with Option 63 (EV-DO Demodulator), record the displayed Freq Error, Rho
Pilot, and Tau into
8. Verify that the measured values in Step
9. On the power meter, press the Sensor key, the Cal Factor soft key, and then the Freq soft key. Use the
keypad to enter 870.03 MHz as the input signal frequency, which sets the power meter to the proper
power sensor calibration factor. Press the System key to display the power reading.
10. Set the MG3700A Frequency to 870.03 MHz.
11. Adjust the MG3700A output so that the power meter reads –10 dBm ± 0.2 dB, and record the actual
value as shown on the power meter into
on page A-34.
12. On the MS2723B or MS2724B, press the Frequency soft key, and enter 870.03 MHz as Center Frequency.
Then wait 15 seconds to allow the MS2723B or MS2724B to update its measured results.
13. Record the MS272xB displayed Channel Power value into
14. For MS2723B or MS2724B with Option 62 (EV-DO RF Measurements), subtract the "MS272xB Reading"
of displayed Channel Power value from the "Power Meter Reading" in Step 11. Then record the
"Calculated Channel Power Error" into
15. For MS2723B or MS2724B with Option 63 (EV-DO Demodulator), record the displayed Freq Error, Rho
Pilot, and Tau into
16. Verify that the measured values in Step
Models MS2723B and MS2724B MM
Table
Table A-95, "At 1930.05 MHz, –50 dBm Level, Idle Slot" on page
6
Table A-91, "At 870.03 MHz, –10 dBm Level, Idle Slot"
Table
Table A-96, "At 870.03 MHz, –10 dBm Level, Idle Slot" on page
14
