Performance Verification
9. Repeat Step
7
and Step
Sensor B readings in the second column.
Procedure:
1. Connect the equipment as shown in
Setup" on page
2-23, disconnecting Sensor A from the Attenuator, and connecting the RF In port of the
MS2723B or MS2724B to the splitter output via the Attenuator.
to rear panel
connector
Figure 2-10. 50 MHz Amplitude Accuracy Verification – Test Setup
To maintain test setup integrity, do not disconnect Sensor B, the power splitter, or the fixed
Note
attenuator.
2. Set the MS2723B or MS2724B to Spectrum Analyzer mode and then preset the instrument.
3. Set the MS2723B or MS2724B Center Frequency to 50 MHz.
Models MS2723B and MS2724B MM
8
for the other power levels in the first column of
Figure 2-10, "50 MHz Amplitude Accuracy Verification – Test
ML2438A Power Meter
MG369XA Source
10 MHz Reference
MS2724B
PN: 10580-00165 Rev. D
2-2 Spectrum Analyzer Function Verification
Table
Adapter
15NNF50-1.5B
A-18, and record the
Sensor B
1870A
Power Splitter
10 dB
Attenuator
2-23
