Test Records
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Spectrum Analyzer Function Verification (continued)
Table A-11. Spectrum Analyzer DANL (Preamp Off)
Frequency
Start / Stop
10 MHz to 4.0 GHz
> 4.0 GHz to 10.0 GHz
> 10.0 GHz to 13.0 GHz
> 13.0 GHz to 20.0 GHz
Table A-12. Spectrum Analyzer Residual Spurious (Preamp On)
Start Freq Stop Freq
100 kHz
10 MHz
1 GHz
2 GHz
3 GHz
Table A-13. Spectrum Analyzer Residual Spurious (Preamp Off)
Start Freq Stop Freq
9 kHz 100 kHz
100 kHz 10 MHz
10 MHz 2 GHz
2 GHz 3.675 GHz
3.675 GHz 5.35 GHz
5.35 GHz 7.65 GHz
7.65 GHz 9.2 GHz
9.2 GHz 11.1 GHz
11.1 GHz 12.5 GHz
12.5 GHz 13 GHz
13 GHz 15.5 GHz
15.5 GHz 16 GHz
16 GHz 17 GHz
17 GHz 18.5 GHz
18.5 GHz 20 GHz
Models MS2723B and MS2724B MM
RBW VBW
100 kHz 1 kHz
100 kHz 1 kHz
100 kHz 300 Hz
100 kHz 300 Hz
Measured Values (Marker 1)
10 MHz
1 GHz
2 GHz
3 GHz
4 GHz
RBW VBW
300 Hz 30 Hz
3 kHz 300 Hz
100 kHz 10 kHz
30 kHz 3 kHz
30 kHz 3 kHz
10 kHz 3 kHz
3 kHz 300 Hz
1 kHz 100 Hz
3 kHz 100 Hz
1 kHz 100 Hz
10 kHz 1 kHz
10 kHz 1 kHz
10 kHz 1 kHz
10 kHz 1 kHz
10 kHz 1 kHz
PN: 10580-00165 Rev. D
Spectrum Analyzer Function Verification (continued)
Measured dBm
(100 kHz RBW)
dBm
dBm
dBm
dBm
Measured Values (Marker 1)
Calculated dBm
(1 Hz RBW) Specification
≤
dBm
≤
dBm
≤
dBm
≤
dBm
Specification
dBm
dBm
dBm
dBm
dBm
Specification
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
1 Hz
–139 dBm
–136 dBm
–130 dBm
–136 dBm
≤
–100 dBm
≤
–100 dBm
≤
–100 dBm
≤
–100 dBm
≤
–100 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–90 dBm
≤
–85 dBm
≤
–85 dBm
≤
–85 dBm
≤
–85 dBm
≤
–85 dBm
A-5
