Anritsu Spectrum Master MS2723B Maintenance Manual page 132

Option 41 GSM/GPRS/EDGE Demodulator
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Option 41 GSM/GPRS/EDGE Demodulator
Table A-56. At 850 MHz, –50 dBm Level, TCH Pattern (GSM)
Phase Err RMS (Deg)
Table A-57. At 850 MHz, –10 dBm Level, TCH ALL Pattern (GSM)
Phase Err RMS (Deg)
Table A-58. At 1800 MHz, –50 dBm Level, TCH ALL Pattern (GSM)
Phase Err RMS (Deg)
Table A-59. At 1800 MHz, –10 dBm Level, TCH Pattern (GSM)
Phase Err RMS (Deg)
A-24
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00165 Rev. D
Test Records
Specification
Deg ≤ 1 Deg
Specification
≤ 1 Deg
Deg
Specification
≤ 1 Deg
Deg
Specification
≤ 1 Deg
Deg
Models MS2723B and MS2724B MM
