General Information
Factory tests have shown that the equipment that is listed above will provide satisfactory results at
20 GHz (the upper limit of the MS2724B) even though the chart above specifies 18 GHz (per
Caution manufacturers specifications). Many Type N cables have excessive loss for testing the spectrum
analyzer section of the instrument up to 20 GHz. An SMA cable or K cable should therefore be
installed on the MG synthesizer for all spectrum analyzer tests on the MS2724B.
Table 1-2. Test Equipment Required for Verifying Functions of Installed Options
Instrument
Synthesizer
Vector Signal Generator
Power Meter
Power Sensor
Frequency Counter
Programmable Attenuator
Fixed Attenuator
Power Splitter
RF Power Amplifier
Adapter
Adapter
Adapter
Adapter
Adapter
50 Ohm Termination
High Power Load
Models MS2723B and MS2724B MM
Critical Specification
Frequency: 0.1 Hz to 20 GHz,
+16 dBm power
Frequency: 100 kHz to 3 GHz
Power Range: –70 to + 20 dBm
Frequency: 10 MHz to 18 GHz
Power Range: –60 to +20 dBm
Frequency: 20 GHz
Frequency: DC to 2 GHz
Attenuation:100 dB (1 and 10 dB steps)
Frequency Range:
DC to 18 GHz
Attenuation: 10 dB
Frequency: DC to 18 GHz
Frequency:100 to 1000 MHz
Gain: 35 dB min
Frequency: DC to 20 GHz
N(m)-N(m), 50 Ohm
Frequency: DC to 20 GHz
K(m)-N(f), 50 Ohm
Frequency: 881.5 MHz
BNC(m) to N(f), 50 Ohm
Frequency: 881.5 MHz
SMA(m) to N(f), 50 Ohm
Frequency: 881.5 MHz
SMA(m) to SMA(m), 50 Ohm
Frequency: DC to 18 GHz
DC to 18 GHz, 10W
PN: 10580-00165 Rev. D
1-3 Recommended Test Equipment
Recommended Manufacturer/Model
Anritsu Model MG3692A or MG3692B
with options 2A, 4, 15, and 22
Anritsu Model MG3700A with Options
MG3700A-002 and MG3700A-021
Anritsu Model ML2438A
Anritsu Model MA2482D with Option 1
(Quantity 2)
Anritsu Model MF2412B
Anritsu Model MN63A
Aeroflex/Weinschel Model 44-10
(Quantity 2)
Aeroflex/Weinschel Model 1870A
Mini Circuits Model TIA-1000-1R8
(Quantity 2 BNC(m) to N(f) Adapters
required)
Maury Microwave Model 8828B
Quantity: 2 each [One each required
only if Anritsu Coupler and Circulator are
used]
Anritsu Model 34RKNF50
Midwest Microwave Model
ADT-2615-NF-BNM-02 (Quantity 2)
Midwest Microwave Model
ADT-2582-NF-SMM-02 (Quantity 4)
[Required only if Anritsu Coupler and
Circulator are used.]
Midwest Microwave Model
ADT-2594-MM-SMA-02 [Required only if
Anritsu Coupler and Circulator are used.]
Anritsu Model 28N50-2
Aeroflex/Weinschel Model M1418
a
b c
