Channel Power Accuracy (5 Mhz Bandwidth And 5 Ms Frame Length - Anritsu Spectrum Master MS2723B Maintenance Manual

Test Records
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Option 66 Mobile WiMAX RF Measurements

Channel Power Accuracy (5 MHz Bandwidth and 5 ms Frame Length)

Table A-101.Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –15.0 dBm)
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Table A-102.Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –50.0 dBm)
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Table A-103.Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –15.0 dBm)
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Table A-104.Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –50.0 dBm)
Power Meter Reading
MS272xB Reading
Calculated Channel
Power Error
Models MS2723B and MS2724B MM
Option 66 Mobile WiMAX RF Measurements
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00165 Rev. D
Specification
dBm –15 dBm ± 0.2 dB
dBm –15 dBm ± 0.2 dB
dB ±1.5 dB
Specification
dBm –50 dBm ± 0.2 dB
dBm –50 dBm ± 0.2 dB
dB ±1.5 dB
Specification
dBm –15 dBm ± 0.2 dB
dBm –15 dBm ± 0.2 dB
dB ±1.5 dB
Specification
dBm –50 dBm ± 0.2 dB
dBm –50 dBm ± 0.2 dB
dB ±1.5 dB
A-37
