Input Related Spurs For -30 Dbm Input At 1000 Mhz; Input Related Spurs For -30 Dbm Input At 3275 Mhz; Input Related Spurs For -30 Dbm Input At 8000 Mhz; Input Related Spurs For -30 Dbm Input At 15000 Mhz - Anritsu Spectrum Master MS2723B Maintenance Manual

Spectrum Analyzer Input-Related Spurious Verification
Models Firmware Revision: ________________ Operator: ________________ Date: ______________
MS2723B
MS2724B
Serial Number: ________________ Options: ___________________________________________________
Spectrum Analyzer Input-Related Spurious Verification
Input Related Spurs for –30 dBm Input at 1000 MHz
Table A-14. Measured Input Signal Level at 1000 MHz
Start Freq Stop Freq
1000 MHz Center
Frequency
719 MHz 721 MHz
Input Related Spurs for –30 dBm Input at 3275 MHz
Table A-15. Measured Input Signal Level at 3275 MHz
Start Freq Stop Freq
3275 MHz Center
Frequency
2425 MHz 3274 MHz
3276 MHz 4125 MHz
Input Related Spurs for –30 dBm Input at 8000 MHz
Table A-16. Measured Input Signal Level at 8000 MHz
Start Freq Stop Freq
8000 MHz Center
Frequency
7719 MHz 7721 MHz
Input Related Spurs for –30 dBm Input at 15000 MHz
Table A-17. Measured Input Signal Level at 15000 MHz
Start Freq Stop Freq
15000 MHz Center
Frequency
14719 MHz 14721 MHz
A-6
Measured Spur Level
Measured Spur Level
Measured Spur Level
Measured Spur Level
PN: 10580-00165 Rev. D
Calculated IRS
dBm
dBm
Calculated IRS
dBm
dBm
dBm
Calculated IRS
dBm
dBm
Calculated IRS
dBm
dBm
Test Records
Specification
≤ –60 dBc
dBc
Specification
≤ –50 dBc
dBc
dBc ≤ –50 dBc
Specification
≤ –60 dBc
dBc
Specification
≤ –60 dBc
dBc
Models MS2723B and MS2724B MM
