GE Healthcare
REV 1
– The Worklist title shows the date and time of the last update (manual or from HIS/RIS).
– Click the (Browser) button to return to the Browser window.
– By default, when the window opens, the Worklist is sorted by
list in which the number of images is zero is selected, the cursor is in the first selection criteria
entry field, and the default push-button is Start Exam.
– The Worklist information is displayed in columns. You can sort the entries according to the
information in any column, in ascending or descending order, by clicking the title at the head of
the column. For example, to sort on patient name, click the (
are automatically displayed in ascending order of name, and a + sign appears in front of the
title (+Patient Name). Click the button again; a – sign appears in front of the title (–Patient
Name), and the entries are now displayed in descending order of name.
– Items in the Worklist are selected/deselected in the usual way by pointing and clicking.
Non-consecutive multiple items are selected by holding down the Control key while clicking. To
select a range of consecutive multiple items, select an item, then hold down the Shift key while
clicking another; both items and all in between are selected.
– To find and select an item in the list, use the Selection Criteria at the top of the window. As
soon as a character entry is made in one of the boxes (Patient ID, Patient Last Name,
Accession #), the window scrolls to show and select the first matching entry. When an entry is
made in one of the criteria boxes, the other two are automatically cleared.
– Click on the (Refresh Worklist) button to download the current worklist from the configured
Dicom Worklist Provider. If the Dicom worklist feature is not installed, or the Provider is not
configured, this button is greyed out and not active.
While the list is being updated, an indicator WORKLIST LOAD IN PROGRESS... is displayed,
the Refresh Worklist button becomes Cancel Load, and all buttons except Cancel Load and
Browser are disabled.
– Click (Query...) to display the Query definition window, to define the networked Worklist
parameters.
– To delete selected patients, click the (Delete) push-button. To delete all patients, click the
Delete All push-button. User confirmation is requested before deletion.
– Click (New Patient...) to display an empty Medical Procedure Card window, allowing a new
patient to be added to the list.
– Click the (Edit...) button (only active if a single item is selected) to display the Medical
Procedure Card window with data for the selected item, allowing you to view and/or add
information.
– With the correct patient selected in the Worklist, click (Start Exam) or double-click your
selection to display the Viewer window and allow image acquisition for the scheduled patient.
Senographe 2000 D Acquisition System
Patient Name
Patient Name
86
OM 5179217–1–100
, the first item in the
) button. The entries
