K I N G S B R I D G E - F 2 5 0 1 0
INSTALLATION AND OPERATING INSTRUCTIONS
17'-8"
29'-8"
*Actual assembly time may vary
KidKraft, Inc .
4630 Olin Road
Dallas, Texas 75244 USA
customerservice@kidkraft .com
canadacustomerservice@kidkraft .com
1 .800 .933 .0771
972 .385 .0100
For online parts replacement visit
https://parts .kidkraft .com/
WARNING
Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE -30' 6" x 29'8" area requires Protective Surfacing. See page 3.
30'-6"
18'-6"
MAXIMUM VERTICAL FALL HEIGHT - 6' 7"
CAPACITY - 14 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as multi-unit residences, schools, churches,
nurseries, day cares or parks.
Warning. Only for domestic use.
KidKraft Netherlands BV
Olympisch Stadion 29
1076DE Amsterdam
The Netherlands
europecustomerservice@kidkraft .com
+31 20 305 8620 M-F from 09:00 to 17:30
(GMT+1)
For online parts replacement visit
https://parts .kidkraft .eu/
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions
often and give them to any future owner of this play set.

Table of Contents

Protective Surfacing Guidelines . . . . . . . . . pg . 3
Keys to Assembly Success . . . . . . . . . . . . . pg . 6
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . .pg . 8-18
Step-By-Step Instructions . . . . . . . . . .pg . 19-112
Installation of I .D ./Warning Plaque . . . . . pg . 113
Registration . . . . . . . . . . . . . . . . . . . . Last Page
9405010
18-24 Hrs*
Two person
assembly
Rev 07/08/2019

Advertisement

Table of Contents
loading

Related Manuals for KidKraft KINGSBRIDGE

Summary of Contents for KidKraft KINGSBRIDGE

  • Page 1: Table Of Contents

    Protective Surfacing Guidelines . . . . . . . . . pg . 3 Instructions for Proper Maintenance . . . . . . pg . 4 KidKraft, Inc . KidKraft Netherlands BV About Our Wood –...

  • Page 2: Warnings And Safe Play Instructions

    Warnings and Safe Play Instructions CONTINUOUS ADULT SUPERVISION REQUIRED. Most serious injuries and deaths on playground equipment have occurred while children were unsupervised! Our products are designed to meet mandatory and voluntary safety standards. Complying with all warnings and recommendations in these instructions will reduce the risk of serious or fatal injury to children using this play system.

  • Page 3: Protective Surfacing Guidelines

    Protective Surfacing - Reducing Risk of Serious Head Injury From Falls. One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM F1292.

  • Page 4: Instructions For Proper Maintenance

    Instructions for Proper Maintenance Your KidKraft Play System is designed and constructed of quality materials with your child’s safety in mind. As with all outdoor products used by children, it will weather and wear. To maximize the enjoyment, safety and life of your Play Set, it is important that you, the owner, properly maintain it.

  • Page 5: About Our Wood - Limited Warranty

    About Our Wood KidKraft Premium Play Systems uses only premium playset lumber, ensuring the safest product for your children’s use. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to weathering which can change the appearance of your set.

  • Page 6: Keys To Assembly Success

    Keys to Assembly Success Tools Required • Tape Measure • #1, #2 & #3 Phillips • Open End Wrench • 3/16” Hex Key • Carpenters Level or Robertson Bits (7/16”, 1/2” & 9/16”) • 8’ Step Ladder • Carpenters Square or Screwdriver •...
  • Page 7 Your Key To Quick Assembly SORTING WOOD PARTS INTO EACH ASSEMBLY STEP WILL SAVE TIME! Step Step Step SAVE TIME - TIP #1: Wood parts are found in Box 2, 3, 4 & 5. Open each box with wood parts and look for the Key Number stamped on the end of the wood part (see chart below).

  • Page 8: Part Id

    Part Identification (Next Generation E) 1pc. - 2757 1pc. - 2648 - 1 x 4 x 40-5/8 - Floor Board 3632648 LT Post Assembly 1-1/4 x 2-1/2 x 87" 37632757 8pc. - 2609 - 1 x 5 x 40-5/8" - Floor Board 3632609 2pc.
  • Page 9 Add On "G" Part Identification (Quantities per box) (2 Boxes) 2pc. - 9082 MOD Sunburst Bottom 1 x 4 x 30" - 3639082 4pc. - 2759 Roof End 1-1/4 x 3 x 10" - 3632759 4pc. - 2760 - Roof Support 1¼ x 2¼ x 37½" - 3632760 1pc.
  • Page 10 Add on "H" Part Identification (Reduced Part Size) Nominal Size Actual Size 1pc. - 2648 - 1 x 4 x 40-5/8 - Floor Board - 3632648 3pc. - 2781 - 1 x 6 x 19" - RK Board B 5/4 x 5 15/16 x 4-1/4 3632781 5/4 x 6...
  • Page 11 Add on "H" Hardware Identification (Actual Size) (2) LW2 - 5/16" Lock Washer - (51303300) (36) TN1 - 1/4" T - Nut (54503200) (5) FW0 - 3/16" Flat Washer - (51103100) (41) LW1 - 1/4" Lock Washer - (51303200) (44) FW1 - 1/4" Flat Washer - (51103200) (2) TN2 - 5/16"...
  • Page 12 Add on "H" Hardware Identification (Actual Size) 1/4 x 1-3/8" 2pc. WL3 - Wafer Lag - (52613216) Wafer Bolt w/ Nylok 5/16 x 1" 2pc. WB1 - - (53613310) Screw 1/4 x 3" 2pc. LS3 - Lag - (52213230) 1/4 x 2-1/2" (17) WL5 - Wafer Lag - (52613222) Hex Bolt 1/4 x 1-1/4"...
  • Page 13 (3206020) 1pc. - Gable Clock Assembly (3320164) 1x - Welded Chain Bag (3200170) - Door Bumper (9331632) 1x KidKraft ID Plaque (1) KidKraft (9320374) ID Plaque (9320370) 1x - Swing Hanger (6 Pk) 54" x 4 (3206106) 1x - Hand Grip...
  • Page 14 Add on "J" Hardware (Actual Size) 5pc. FW0 - 3/16" Flat Washer - 32pc. TN1 - 1/4" T - Nut 5pc. LW2 - 5/16" Lock Washer - (54503200) (51103100) (51303300) 40pc. FW1 - 1/4" Flat Washer - 38pc. LW1 - 1/4" Lock Washer - (51103200) 10pc.
  • Page 15 Add on "J" Hardware (Actual Size) 1/4 x 2-1/2" 16pc. WL5 - Wafer Lag 1/4 x 1-3/8" 2pc. WL3 - Wafer Lag (52613222) (52613216) 1/4 x 3" 2pc. LS3 - Lag Screw - (52213230) 5/16 x 1" 2pc. WB1 - Wafer Bolt w/ Nylok 1/4 x 1-1/4"...
  • Page 16 Part Identification (Add On "T") 2pc. - 9089 Upper Tunnel Insert 2pc. - 9088 Tunnel Side Joist 1-1/4 x 3 x 36" - 3639088 1.27 x 8-1/4 x 18-51/64" - 37639089 7pc. - 9092 Floor Board 1 x 5 x 16-7/8" - 3639092 1pc.
  • Page 17 Part Identification (Reduced Part Size) (1) SL Gusset 1¼ x 3 x 15¾" (1) Lower SL Insert 1.36 x 8-1/8 x 26¼" 8934 3638934 37638935 8935 (1) TNR Upright 1¼ x 3 x 20¼" 8965 3638965 (1) TNR Ground Brace 1¼ x 3 x 32¼" 8963 3638963 Part Identification (Actual Part Size)
  • Page 18 Part Identification (Reduced Part Size) 9x - TNR 2 Slide Elbow (3310221) 1x - TNR 2 Slide Exit Top (3310224) 1x - TNR3 Short Exit (3310232) 1x - TNR 3 Tube Support (9203601) 10x - TNR 2 Clamp Ring 1x - TNR 2 Slide Clamp Ring (9300220) (Yellow) (10Pk) 10pcs number 3300220...

  • Page 19: Step-By-Step Instructions

    • The carton I .D . stamp is located on the end of each carton . The tracking number is located on the KidKraft ID Plaque (9320374) . • Please retain this information for future reference . You will need this information if you contact the Consumer Relations Department .
  • Page 20 Step 1: Side Wall Prep Part 1 It is important to assemble the frame on a flat, smooth surface. A: Place (2771) End Post and (2770) End Post Left side by side with the grooves facing up and in . Put (2770) End Post Left on the right hand side .
  • Page 21 Step 1: Side Wall Prep Part 2 It is important to assemble the frame on a flat, smooth surface. D: Turn the assembly over, place (2774) Upright in the middle grooves of (2775) Panel Cross Support and (2772) Panel Floor Support then attach all boards with 8 (H9) 1/4 x 1-1/4” Hex Bolts (with lock washer and flat washer) connecting to the previously installed t-nuts.
  • Page 22 Step 2: Front Wall Prep Part 1 It is important to assemble the frame on a flat, smooth surface. A: Place (2771) End Post and (2770) End Post Left side by side with the grooves facing up and in . (2770) End Post Left on the right hand side .
  • Page 23 Step 2: Front Wall Prep Part 2 It is important to assemble the frame on a flat, smooth surface. D: Turn the assembly over then attach all boards with 6 (H9) 1/4 x 1-1/4” Hex Bolts (with lock washer and flat washer) connecting to the previously installed t-nuts.
  • Page 24 Step 3: Swing Wall Prep Part 1 It is important to assemble the frame on a flat, smooth surface. A: Place (2757) LT Post Assembly and (2758) RT Post Assembly on a hard, flat surface with the notches facing down. The top of the post assemblies have the longer notches. (fig. 3.1) B: Tap 1 (TN2) 5/16”...
  • Page 25 Step 3: Swing Wall Prep Part 2 It is important to assemble the frame on a flat, smooth surface. C: Turn the (2757) LT Post Assembly and (2758) RT Post Assembly over and place 2 (2756) Siding Assemblies on top so one sits flush with the top of the middle groove and the second fits flush with the top of the bottom groove.
  • Page 26 Step 3: Swing Wall Prep Part 3 It is important to assemble the frame on a flat, smooth surface. E: Attach (2630) SW Top to (2757) LT Post Assembly and (2758) RT Post Assembly with 2 (WB1) 5/16 x 1” Wafer Bolts (with flat washer) connecting to previously installed t-nuts.

  • Page 27: Fig. 3.8

    Step 3: Swing Wall Prep Part 4 It is important to assemble the frame on a flat, smooth surface. I: Attach the top board in each (2756) Siding Assembly to (2757) LT Post Assembly and (2758) RT Post Assembly with 4 (S30) #8 x 1-1/16” Wood Screws per board. (fig. 3.8 and 3.9) J: Attach the remaining boards in each (2756) Siding Assembly to (2757) LT Post Assembly and (2758) RT Post Assembly with 2 (S0) #8 x 7/8”...

  • Page 28: Fig. 4.1

    Step 4: Fort Assembly Part 1 It is important to assemble the Fort Assembly on a flat, smooth surface. A: Place Swing Wall from Step 3 between 2 Side Walls from Step 1, noticing the wall orientations . The tops and bottoms of the walls should be flush.
  • Page 29 Step 4: Fort Assembly Part 2 B: Place Front Wall from Step 2 between the Side Walls noticing the wall orientation . The tops and bottoms of the walls should be flush. Make sure the walls are square then using the pilot holes as a guide pre-drill with a 3/16”...

  • Page 30: X 2607 Diagonal 1-1/4 X 3 X 22" 4 X

    Step 4: Fort Assembly Part 3 C: Loosely attach 1 (2607) Diagonal to left (2778) SW Ground MOD with 1 (H10) 1/4 x 2-1/4” Hex Bolt (with lock washer, flat washer and t-nut). (fig. 4.5) D: Place each (2607) Diagonal tight and flush to the front of the Swing Wall then pre-drill pilot holes with a 3/16” drill bit and attach each (2607) Diagonal to the Swing Wall with 1 (LS3) 1/4 x 3”...
  • Page 31 Step 5: Floor Assembly Part 1 Complete Step 5 for both Fort Assemblies. A: From inside of the assembly centre (2608) Floor Joist over the pilot holes in both (2768) Panel Floors in the Swing and Front Walls, measure 5/8” down from the top of boards then attach (2608) Floor Joist to each board using the left and centre holes with 2 (S4) #8 x 3”...
  • Page 32 Step 5: Floor Assembly Part 2 B: On the inside of both the Side Walls place 1 (2777) Side Joist MOD against each (2772) Panel Floor Support, line up bolt holes then loosely attach with 2 (H11) 1/4 x 2-3/4” Hex Bolts (with lock washer, flat washer and t-nut) per joist.
  • Page 33 Step 5: Floor Assembly Part 3 C: Fasten each (2777) Side Joist MOD to each (2772) Panel Floor Support with 4 (S3) #8 x 2-1/2” Wood Screws per board as shown in fig. 5.6. D: Tighten all (H11) 1/4 x 2-3/4” Hex Bolts in both (2777) Side Joist MOD . Fig.
  • Page 34 Step 5: Floor Assembly Part 4 E: Starting at the Swing Wall place (2648) Floor Board followed by 8 (2609) Floor Boards . Make sure all boards are evenly spaced then attach to (2608) Floor Joist and each (2777) Side Joist MOD with 5 (S20) #8 x 1-3/8” Wood Screws per board.
  • Page 35 Step 6: Attach Tunnel Inserts Part 1 MOVE FORT TO FINAL LOCATION PRIOR TO STAKING FINAL LOCATION MUST BE LEVEL GROUND Fig. 6.1 A: The Fort Assembly on the left will be referred to Top View as Unit A and the Fort Assembly on the right will be 33-1/2”...
  • Page 36 Step 6: Attach Tunnel Inserts Part 2 D: Place 1 (9084) Lower Tunnel Insert in each of the openings facing each other, tight to the floor boards and attach with 4 (S0) #8 x 7/8” Truss Screws per insert. (fig. 6.3 and 6.4) E: In the opening in Unit B place 1 (9089) Upper Tunnel Insert tight to (2775) Panel Cross Support and attach with 4 (S0) #8 x 7/8”...
  • Page 37 Step 7: Tunnel Floor Assembly Part 1 A: Tap in 2 (TN2) 5/16” T-nuts in each (9088) Tunnel Side Joist. (fig. 7.1) B: With the (TN2) 5/16” T-nuts at the bottom measure 1” in from both ends of each (9088) Tunnel Side Joist then attach 1 (9086) Tunnel Top to each end with 4 (S4) #8 x 3”...
  • Page 38 Step 7: Tunnel Floor Assembly Part 2 D: Flush to the ends and sides of both (9088) Tunnel Side Joist place 1 (9087) Floor Board followed by 7 (9092) Floor Boards. Make sure the last board is flush to the ends of each (9088) Tunnel Side Joist then attach all floor boards with 4 (S20) #8 x 1-3/8”...
  • Page 39 Step 8: Attach Tunnel Floor Assembly to Fort A: Place Tunnel Floor Assembly between Unit A and Unit B tight to each (9084) Lower Tunnel Insert then attach with 4 (S4) #8 x 3” Wood Screws from the inside and 4 (S0) #8 x 7/8” Truss Screws from the outside per end . (fig.
  • Page 40 Step 9: Tunnel Assembly Part 1 A: Bend all 4 MOD Tunnel Panels as shown in fig. 9.1. B: Match 2 MOD Tunnel Panels together by making a slight “V” with the pieces so the peak of the “V” faces away from you .
  • Page 41 Step 9: Tunnel Assembly Part 2 E: Attach the tops of each Tunnel Side together using 2 (MB1) #12 x 1/2” Pan Bolts (with #12 Lock Nut) per side. (fig. 9.4 and 9.5) F: Join the 2 Tunnel Sides together so the tops are tight together and attach with 6 (MB1) #12 x 1/2” Pan Bolts (with #12 Lock Nut).
  • Page 42 Step 10: Attach Tunnel Assembly to Fort Part 1 A: From inside Unit A slide the Tunnel Assembly through the opening onto the Tunnel Floor Assembly so it sits tight to the (9089) Upper Tunnel Insert on Unit B, both posts and both (2774) Uprights and the tunnel floor boards.
  • Page 43 Step 10: Attach Tunnel Assembly to Fort Part 2 B: Attach Tunnel Assembly to the posts and (2774) Uprights through the connector tab holes with 4 (S10) #8 x 1” Pan Screws per end. (fig. 10.4 and 10.5) C: Attach Tunnel Assembly to (9089) Upper Tunnel Insert with 4 (S10) #8 x 1” Pan Screws. (fig. 10.4 and 10 .6) D: Attach Tunnel Assembly to each (9088) Tunnel Side Joist with 6 (S10) #8 x 1”...
  • Page 44 Step 10: Attach Tunnel Assembly to Fort Part 3 E: From inside Unit A place 1 (9089) Upper Tunnel Insert tight to (2775) Panel Cross Support and attach with 4 (S0) #8 x 7/8” Truss Screws. (fig. 10.8 and 10.9) F: Attach Tunnel Assembly to (9089) Upper Tunnel Insert with 4 (S10) #8 x 1”...
  • Page 45 Beam as shown in fig. 11.3. IT IS IMPORTANT THAT THIS BOLT IS ATTACHED. IT WILL MINIMIZE CHECKING OF WOOD. D: Attach KidKraft Plaque to centre of (2614) Engineered Beam (over top of t-nut) using 4 (S18) #6 x 1” Wood Screws. (fig. 11.4) Swing Hanger x 6 Fig.
  • Page 46 Step 12: Swing End Assembly A: Loosely attach 2 (2613) Heavy SW Posts to (2615) SW Upright using 2 (G7) 5/16 x 5-1/2” Hex Bolts (with lock washer, flat washer and t-nut). Notice 2 bolt holes at top of (2615) SW Upright and orientation of angle. (fig.
  • Page 47 Step 13: Attach Swing End to Swing Beam A: Place Swing End Assembly against Swing Beam Assembly then place 1 Beam Bracket on each side of the assembly (they are specific for left and right side) and attach with 5 (G21) 5/16 x 3-3/4” Hex Bolts (with 2 flat washers and 1 lock nut).
  • Page 48 Step 14: Attach Swing Assembly To Fort A: On Unit B place Swing Assembly against top of (2630) SW Top, make sure assembly is level then attach from inside the fort assembly into each L-Beam Bracket with 4 (G8) 5/16 x 2” Hex Bolts (with 2 flat washers and 1 lock nut).
  • Page 49 Step 15: Install Ground Stakes A: In the 6 places shown in fig. 15.1 drive the Rebar Ground Stakes 13” into the ground against all 4 (2607) Diagonals and both (2613) Heavy SW Posts . Be careful not to hit the washer while hammering stakes into the ground as this could cause the washer to break off .
  • Page 50 Step 16: Install Upper and Lower Jambs Part 1 A: In the lower opening of each Unit A Side Wall and Tunnel Side Wall and the outer Side Wall in Unit B place 1 (2601) Lower Jamb so it measures 17” to the inside of each post then attach each (2601) Lower Jamb with 2 Jamb Mounts using 4 (S0) #8 x 7/8”...
  • Page 51 Step 16: Install Upper and Lower Jambs Part 2 B: On the Front Wall in Unit A place 1 (2602) Upper Jamb in the upper opening so it measures 9-5/8” to the inside of the right post and 1 (2601) Lower Jamb in the lower opening so it measures 17” to the inside of each post then attach each board with 2 Jamb Mounts to (2769) Panel BT Frames and (2768) Panel Floor using 4 (S0) #8 x 7/8”...
  • Page 52 Step 17: Install Window and Wall Inserts Part 1 - Unit A Front Wall A: In the lower openings of Unit A Front Wall install 2 (2649) Lower Window Inserts using 9 (S0) #8 x 7/8” Truss Screws per insert. (fig. 17.1, 17.2 and 17.3) B: In the upper openings of Unit A Front Wall install 1 (8935) Lower SL Insert with 4 (S0) #8 x 7/8”...
  • Page 53 Step 17: Install Window and Wall Inserts Part 2 - Unit A Tunnel Side Wall C: In the lower opening of Unit A Tunnel Side Wall under the tunnel install 1 (2649) Lower Window Insert and in the upper opening beside the tunnel install 1 (2655) Upper Window Inserts using 9 (S0) #8 x 7/8” Truss Screws per insert.
  • Page 54 Step 17: Install Window and Wall Inserts Part 3 - Unit A Side Wall D: In the upper openings of Unit A Side Wall install 2 MOD Arches using 3 (S0) #8 x 7/8” Truss Screws per insert . (fig. 17.8, 17.9 and 17.10) E: In the left hand upper opening and both lower openings install 3 (649A) Short Half Walls using 4 (S0) #8 x 7/8”...
  • Page 55 Step 17: Install Window and Wall Inserts Part 4 - Unit B Front Wall F: In the lower opening of Unit B Front Wall install 1 (2665) Half Wall Insert using 4 (S0) #8 x 7/8” Truss Screws . (fig. 17.12, 17.13 and 17.14) G: In the right hand upper opening of Unit B Front Wall install 1 (2655) Upper Window Insert using 9 (S0) #8 x 7/8”...
  • Page 56 Step 17: Install Window and Wall Inserts Part 5 - Unit B Tunnel Side Wall H: In the upper opening of Unit B Tunnel Side Wall beside the tunnel install 1 (2655) Upper Window Inserts using 9 (S0) #8 x 7/8” Truss Screws. (fig. 17.17, 17.18 and 17.19) I: In the lower opening of Unit B Tunnel Side Wall install 1 (2665) Half Wall Insert using 4 (S0) #8 x 7/8”...
  • Page 57 Step 17: Install Window and Wall Inserts Part 6 - Unit B Side Wall J: In the lower right hand opening of Unit B Side Wall install 1 (2649) Lower Window Insert using 9 (S0) #8 x 7/8” Truss Screws. (fig. 17.21, 17.22 and 17.23) K: In the upper openings and left hand lower opening of Unit B Side Wall install 3 MOD 3-Pane Transoms with 4 (S0) #8 x 7/8”...
  • Page 58 Step 18: Clock Assembly A: From inside the assembly place (2717) Clock Block centred on the panel of (2655) Upper Window Insert then attach with 1 (S13) #6 x 5/8” Pan Screw. (fig. 18.1 and 18.2) B: On Unit B Front Wall place Gable Clock Assembly centred under window of (2655) Upper Window Insert then attach to (2602) Upper Jamb and (2771) End Post with 2 (S10) #8 x 1”...
  • Page 59 Step 19: Rock Wall Assembly Fig. 19.1 Note: The holes in the rock boards 2776 must orient to the 2780 2780 2781 top of the boards. 2781 2781 2779 7-5/8” Approx x 4 per board Note: Gaps between boards 2-1/4”, not to exceed 2-3/8” Complete Step 19, A-E twice to make 2 Rock Wall Assemblies.
  • Page 60 Step 20: Attach Rock Wall Assembly to Fort Part 1 A: Place the Rock Wall Assemblies centred in openings of Unit A Side Wall and Unit B Front Wall flush as shown below. Attach (2776) Rock Rails using 2 (S11) #8 x 2” Wood Screws per rail. (fig. 20.1, 20.2 and 20.3) B: Attach 1 (2779) Access Board to top of each Rock Wall Assembly, flush to top of (2776) Rock Rails using 4 (S20) #8 x 1-3/8”...
  • Page 61 Step 20: Attach Rock Wall Assembly to Fort Part 2 C: Drive 1 Rebar Ground Stake 13” into the ground against 1 (2776) Rock Rail per assembly then attach with 1 (S7) #12 x 2” Pan Screw per ground stake . Be careful not to hit the washer while hammering stake into the ground as this could cause the washer to break off.
  • Page 62 Step 21: Attach Hand Grip to Fort A: Measure 6” from the top of the floor boards on the left hand side of each Rock Board, pre-drill with a 1/8” drill bit then attach 1 Hand Grip per wall with 2 (WL3) 1/4 x 1-3/8” Wafer Lags per Hand Grip. (fig. 21.1) Hand Grip Fig.
  • Page 63 Step 22: Cafe Table Assembly A: Place 1 (2612) Table Support flush to the notched out ends of 1 (2611) Table Top and attach with 4 (S7) #12 x 2” Pan Screws as shown in fig. 22.1. B: Place Table Top Assembly tight in the opening of Unit B Tunnel Side Wall with the overhang on the outside of the assembly as shown in fig.
  • Page 64 Step 23: Attach Wall Tops A: From inside the assembly place 1 (2804) Wall Top tight to the posts and top of (2665) Half Wall Insert on Front Wall of Unit B and tight to the posts and top of (2756) Siding Assembly on Swing Wall of Unit B then attach to the posts with 2 (S11) #8 x 2”...
  • Page 65 Step 24: Attach Door Components Part 1 A: On the inside of (2709) Door Window Panel measure 15” up from the bottom and attach Catch Plate flush to the edge using 2 (S18) #6 x 1” Wood Screws. (fig. 24.1) B: On the inside of (2709) Door Window Panel measure 22”...
  • Page 66 Step 24: Attach Door Components Part 2 C: On the outside of the (2709) Door Window Panel attach the second Door Handle at approximately the same place as the one on the inside. Use 2 (S13) #6 x 5/8” Pan Screws. (fig. 24.2) D: On the opposite side of the Door Handle measure 5/8”...
  • Page 67 Step 24: Attach Door Components Part 3 E: On the outside bottom edge of (2709) Door Window Panel measure 1” up from the hinge and install 1 Door Bumper using 1 (S0) #8 x 7/8” Truss Screw . There should be a measurement of 5/8” from the back of (2709) Door Window Panel to the screw hole .
  • Page 68 Step 25: Attach Door Assembly to Fort A: On the Tunnel Side Wall of Unit A measure 5/8” up from the top of (2769) Panel BT Frame and a maximum 5/8” from the inside edge of (2601) Lower Jamb then attach the remaining side of the hinges to (2601) Lower Jamb using 3 (S13) #6 x 5/8”...
  • Page 69 Step 26: Attach Door Stop A: In the notched out opening of (2715) Door Stop attach the Magnetic Catch using 2 (S18) #6 x 1” Wood Screws. (fig. 26.1) Important: Use a hand held screw driver and DO NOT over tighten. B: On the inside of the assembly, attach (2715) Door Stop to (2770) End Post Left with 3 (S11) #8 x 2”...
  • Page 70 Step 27: Counter Assembly Part 1 A: Flush to each end and to the top of (2687) Counter Back attach 1 (5736) Counter Joist per end with 1 (S20) #8 x 1-3/8” Wood Screw per joist. Notice the remaining holes at the bottom of (2687) Counter Back. (fig. 27.1) B: Place the remaining 2 (5736) Counter Joists centred over the pilot holes in the middle of (2687) Counter Back and flush to the top of the board, then attach, in the top holes, with 1 (S20) #8 x 1-3/8”...
  • Page 71 Step 27: Counter Assembly Part 2 C: On the inside of the Swing Wall on Unit B place Counter Assembly so the top of (2687) Counter Back is flush to the top of (2756) Siding Assembly then attach with 5 (S20) #8 x 1-3/8” Wood Screws. (fig. 27.2 and 27.3) Tunnel Side Wall Unit B...
  • Page 72 Step 27: Counter Assembly Part 3 D: Place 1 (6136) Counter Brace flush to the front and outside edge of each outer (5736) Counter Joist and tight to Swing Wall then attach with 2 (S3) #8 x 2-1/2” Wood Screws per brace. (fig. 27.4 and 27.5) Fig.
  • Page 73 Step 27: Counter Assembly Part 4 E: Place (2686) Counter Front against (5736) Counter Joists so the ends are flush and the centre (5736) Counter Joists are centred over the pilot holes . Measure 5/8” down from the top of (2686) Counter Front on both ends and attach to the (5736) Counter Joists with 4 (S20) #8 X 1-3/8”...
  • Page 74 Step 27: Counter Assembly Part 5 F: Tight to (2687) Counter Back attach (2685) Counter Top to each (5736) Counter Joist with 4 (TS) #6 x 30 mm Trim Screws. (fig. 27.7) G: Tight to (2685) Counter Top and flush to the outside edges of the outer (5736) Counter Joists attach 1 (5536) Counter Side per joist with 3 (TS) #6 x 30 mm Trim Screws per board.
  • Page 75 Step 27: Counter Assembly Part 6 J: Place Faucet and 2 Sink Knobs in opening of Sink and attach Sink Knobs with included hardware. (fig. 27.9) Important: Use a hand held screw driver and DO NOT over tighten. Fig. 27.9 Faucet Sink Knob Sink Knob...
  • Page 76 Step 27: Counter Assembly Part 7 K: Place Sink and Stove in the openings of the Counter Assembly then attach 4 Mount Clips with included hardware to the bottom of the Sink and Stove to secure in place. (fig. 27.10 and 27.11) Important: Use a hand held screw driver and DO NOT over tighten.
  • Page 77 Step 28: Attach Utensil Shelf A: From inside the assembly, centred in the top of (2768) Panel Floor above the counter attach Utensil Shelf with 2 (S13) #6 x 5/8” Pan Screws as shown in fig. 28.1 and 28.2. B: Attach Pot, Pan and Spatula to the Utensil Shelf. (fig. 28.2 and 28.3) Fig.
  • Page 78 Step 29: Slide Section Assemblies Part 1 Note: When installing Pan Bolts make sure to look at holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. (fig. 29.3) A: Fit 2 TNR2 Slide Elbows together and attach with 8 (PB1) 1/4 x 3/4”...
  • Page 79 Step 29: Slide Section Assemblies Part 2 Note: When installing Pan Bolts make sure to look at holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. (fig. 29.3) D: Attach TNR2 Slide Exit Top and the remaining TNR2 Slide Elbow together using 8 (PB1) 1/4 x 3/4”...
  • Page 80 Step 30: Attach Flange Assembly to Fort Part 1 A: With a helper place the Flange Assembly flush to the top opening in the Front Wall on Unit A as shown in fig. 30 .1, then pre-drill 1/8” pilot holes in (8935) Lower SL Insert for the 4 bottom mounting locations (approximate spots where circles are on figure), making sure the pre-drilled holes are a minimum of 1”...
  • Page 81 Step 30: Attach Flange Assembly to Fort Part 2 D: Place (8934) SL Gusset tight to (2768) Panel Floor, flush to the top of the bottom opening and attach to Flange Assembly with 2 (S6) #12 x 1” Pan Screws. (fig. 30.4 and 30.5) E: Pre-drill pilot hole with a 3/16”...
  • Page 82 Step 31: Attach Elbow Assembly to Flange Assembly Part 1 Note: When installing Pan Bolts make sure to look at holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. Keep all bolts loose until further step.
  • Page 83 Step 31: Attach Elbow Assembly to Flange Assembly Part 2 Note: When installing Pan Bolts make sure to look at holes so bolts Fig. 31.5 go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. Keep all bolts loose until further step.
  • Page 84 Step 32: Attach Elbow Assembly to Elbow Assembly Part 1 Note: When installing Pan Bolts make sure to look at holes so bolts go Fig. 32.1 through the side with the round recess and the lock nuts go through the side with the hexagonal recess. Keep all bolts loose until further step.
  • Page 85 DO NOT USE DO NOT USE USE IMAGE Step 32: Attach Elbow Assembly to Elbow Assembly USE IMAGE Part 2 Note: When installing Pan Bolts make sure to look at holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. Keep all bolts loose until further step.
  • Page 86 Step 33: TNR Brace Assembly A: Attach (8965) TNR Upright to (8963) TNR Ground Brace with 1 (H8) 1/4 x 4-1/4” Hex Bolt (with lock washer, flat washer and t-nut) in the top hole. Make sure both boards are square then attach with 1 (S11) #8 x 2”...
  • Page 87 Step 34: Attach Elbow Assemblies and TNR2 Slide Support Note: When installing Pan Bolts make sure to look at holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess. Keep all bolts loose until further step.
  • Page 88 Step 35: Attach TNR Brace Assembly A: Use (8965) TNR Upright as a guide to judge the proper bolt location, remove the bottom pan bolt and nut . The bolt will no longer be needed, but keep the lock nut. (fig. 35.1 and 35.2) B: Attach the top of the TNR3 Post Mount to TNR2 Slide Clamp Ring using 1 (PB2) 1/4 x 1-1/4”...
  • Page 89 Step 36: Attach TNR2 Slide Exit to Exit Elbow Assembly A: Insert flange of Exit Elbow Assembly (slide elbow) into the slots on TNR3 Short Exit. (fig. 36.1) B: Rotate Slide Exit and use Quadrex Driver as a guide pin so the holes are aligned and attach with 5 (PB1) 1/4 x 3/4”...
  • Page 90 Step 37: Attach Exit End Assembly to Fort Fig. 37.1 Note: When installing Pan Bolts make sure to look at Exit Elbow Top Slide Bolt Holes Assembly holes so bolts go through the side with the round recess and the lock nuts go through the side with the hexagonal recess.
  • Page 91 Step 38: Attach Ground Stake to TNR Upright A: In the spot shown in fig. 38.1 drive 1 Rebar Ground Stake 13” into the ground against the (8965) TNR Upright . Be careful not to hit the washer while hammering stake into the ground as this could cause the washer to break off .
  • Page 92 Step 39: Roof Support Assembly A: Attach 1 (2760) Roof Support to a second (2760) Roof Support at peak using 1 (S4) #8 x 3” Wood Screw . Repeat this step so there are 4 Roof Support Assemblies. (fig. 39.1 and 39.2) Fig.
  • Page 93 Step 40: Roof Panel Assembly A: Place 1 (2751) MOD Roof Bottom tight to the bottom of (2752) MOD Roof Front and (2753) MOD Roof Back . (fig. 40.1) B: Place a (2761) Roof Sleeper C on the middle strip of each Roof Panel Assembly so the ends are flush and attach with 4 (S20) #8 x 1-3/8”...
  • Page 94 Step 41: Roof Assembly Part 1 Complete Step 41, A-D, twice so there are 2 Roof Assemblies A: Place Front Roof Panel against Back Roof Panel so the tops form a peak then tight to the inside edge of the outside slats attach 1 Narrow Angle Bracket per slat with 2 (S0) #8 x 7/8”...
  • Page 95 Step 41: Roof Assembly Part 2 C: Place 1 Roof Support Assembly against one side so the peaks meet and the ends of the roof supports are flush with the ends of the roof panels. Attach with 8 (S11) #8 x 2” Wood Screws. (fig. 41.4) D: Attach the second Roof Support Assembly on the opposite side, peaks to meet and ends are flush with 8 (S11) #8 x 2”...
  • Page 96 Step 41: Roof Assembly Part 3 E: On the inside of each Roof Assembly on the bottom siding of the (2752) MOD Roof Fronts (6th siding down from top of Roof Assembly), measure 1” from each side of (2761) Roof Sleeper C and pre-drill 2 holes with a 3/16”...
  • Page 97 Step 42: Dormer Assembly Part 1 Complete Step 42, A-H, twice to create 2 Dormer Assemblies. A: Lay 2 (8070) Dormer Sides flat on the ground so the tops are tight together and form a peak. The side facing up will be the back. (fig. 42.1 and 42.2) B: Tight to the bottom of both (8070) Dormer Sides place (8073) Dormer Bottom so the outside edges are flush.
  • Page 98 Step 42: Dormer Assembly Part 2 F: Pre-drill with a 1/8” drill bit then attach Dormer Roof Right to Dormer Roof Left, from (8068) Dormer Roof Set at the inside peak with 1 Narrow Angle Bracket using 2 (S5) #8 x 7/8” Truss Screws. (fig. 42.3) G: Place the Dormer Burst Assembly from Step 42, Part 1 on the inside edge of each Dormer Roof and attach with 6 (S30) #8 x 1-1/6”...
  • Page 99 Step 43: Attach Roof Ends Part 1 - Unit A Front Wall A: On the Front Wall of Unit A remove the 2 outside (H9) 1/4 x 1-1/4” Hex Bolts attached at the top of the assembly from Step 2, Part 2 . Leave the T-nuts in . The Flat Washers and Lock Washers will be used in Step B . (fig.
  • Page 100 Step 43: Attach Roof Ends Part 2 - Unit A Front Wall B: Loosely attach 1 (2759) Roof End to each corner of the End Wall, flush to the top of (2769) Panel BT Frame, with 1 (H3) 1/4 x 2-1/2” Hex Bolt per board, using the (FW1) Flat Washer and (LW1) Lock Washer from Step A and connecting to the (TN1) T-nut.
  • Page 101 Step 43: Attach Roof Ends Part 3 - Unit A Front Wall C: Measure overhang so it is 4-7/8” then attach (2759) Roof Ends with 2 (S11) #8 x 2” Wood Screws and 1 (S3) #8 x 2-1/2” Wood Screw per side. Tighten the bolts. (fig. 43.5, 43.6 and 43.7) Fig.
  • Page 102 Step 43: Attach Roof Ends Part 4 - Unit A Swing Wall D: Attach 1 (2759) Roof End to each corner of the Swing Wall, flush to the top of (2630) SW Wall and overhanging 4-7/8” then attach with 2 (S11) #8 x 2” Wood Screws and 1 (S3) #8 x 2-1/2” Wood Screw per (2759) Roof End.
  • Page 103 Step 44: Attach Roof Ends Part 1 - Unit B Side and Tunnel Side Walls A: On the Side and Tunnel Side Walls of Unit B remove the 4 outside (H9) 1/4 x 1-1/4” Hex Bolts attached at the top of the assembly from Step 1, Part 2 . Leave the T-nuts in . The Flat Washers and Lock Washers will be used in Step B.
  • Page 104 Step 44: Attach Roof Ends Part 2 - Unit B Side and Tunnel Side Walls B: Loosely attach 1 (2759) Roof End to each corner of the Side and Tunnel Side Walls, flush to the top of (2775) Panel Cross Supports, with 1 (H3) 1/4 x 2-1/2” Hex Bolt per board, using the Flat Washer and Lock Washer from Step A and connecting to the T-nut.
  • Page 105 Step 44: Attach Roof Ends Part 3 - Unit B Side and Tunnel Side Walls C: Measure overhang so it is 4-7/8” then attach (2759) Roof Ends with 2 (S11) #8 x 2” Wood Screws and 1 (S3) #8 x 2-1/2” Wood Screw per corner. Tighten the bolts. (fig. 44.5, 44.6 and 44.7) Fig.
  • Page 106 Step 45: Attach Roof Assembly to Fort Part 1 A: With 2 people on the ground and at least 1 person in Unit A, lift 1 Roof Assembly up and over the Swing Wall side of the fort. Guide the Roof Assembly onto the fort so all four (2760) Roof Supports sit flush to the front and outside edges of (2759) Roof Ends.
  • Page 107 Step 45: Attach Roof Assembly to Fort Part 2 For Unit A D: Place (9450) Roof Tie so that the angled end is flush against (2761) Roof Sleeper C and the other end is flat against (2775) Panel Cross Support, centered between the Hex Bolts. Attach using 4 (S11) #8 x 2” Wood Screws, making sure that the top 2 screws are installed on an angle as shown in fig.
  • Page 108 Step 46: Sunburst Assemblies A: From inside Unit A place 1 (9082) MOD Sunburst Bottom against the (2760) Roof Supports on the Roof Assembly opening on the Front Wall . Make sure it sits tight to the Roof Assembly on each side then attach with 2 (S20) #8 x 1-3/8”...
  • Page 109 Step 47: Attach Steering Wheel Part 1 A: On the Swing Wall of Unit B measure 2” in from each slat and 1-1/2” down from the top of (2756) Siding Assembly then pre-drill 2 holes with a 3/16” drill bit. (fig. 47.1, 47.2 and 47.3) B: Centred between the first 2 pre-drilled holes measure 3/4”...
  • Page 110 Step 47: Attach Steering Wheel Part 2 D: Place Steering Wheel on the inside of (2756) Siding Assembly then pre-drill with a 1/8” drill bit . Attach Steering Wheel to (2756) Siding Assembly and (9083) Steering Wheel Block with 1 (WL5) 1/4 x 2-1/2” Wafer Lag (with 5/16”...
  • Page 111 Step 48: Attach Flower Box A: On the Tunnel Side Wall on Unit A place 1 Flower Box on (2655) Upper Window Insert centred under the window then attach with 2 (S13) #6 x 5/8” Pan Screws. (fig. 48.1 and 48.2) Unit A Fig.
  • Page 112 Step 49: Attach Slides to Fort A: Place 1 Slide in the centre of each opening of the Side Wall on Unit B, pre-drill with a 1/8” drill bit then attach each slide to fort through the (2772) Panel Floor Support using 3 (S7) #12 x 2” Pan Screws per slide. (fig. 49.1, 49 .2 and 49 .3) Unit B Fig.
  • Page 113 Step 50: Attach Belt Swings and Acro Swing A: Using 1 Threaded Quick Link per chain, join 1 Long Swing Chain to each side of the Swing Belt Seat . Make sure to close the Threaded Quick Link tightly using an adjustable wrench. (fig. 50.1 and 50.2). B: Using 1 Threaded Clip per chain, join the Short Swing Chain to the Acro Bar and Acro Handle .
  • Page 114 Step 51: Bench Assembly A: Open the (2658) Folding Bench Assembly. (fig. 51.1, 51.2 and 51.3) B: Make sure assembly is level then secure with 2 (H1) 1/4 x 1-1/2” Hex Bolts (with lock washer, flat washer and t-nut) per side. (fig. 51.4) C: Tighten the top screws in all 4 Bench Legs.
  • Page 115 Contáctenos en: KidKraft www.KidKraft.com Dallas, TX 75244, Estados Unidos Contact us at: KidKraft Dallas, TX 75244 USA 1-800-933-0771 1-800-933-0771 Tracking Number: Número de Numèro de Suivi: seguimiento: Other Parts Hardware #6 x 5/8” Pan Screw 1 x I.D. Plaque - KidKraft...
  • Page 116 NOTES NOTES...
  • Page 117 NOTES NOTES...
  • Page 118 NOTES NOTES...
  • Page 119 NOTES NOTES...
  • Page 120 Would you recommend the purchase of our products to friends and family? Comments: MAIL TO: Fill out your registration card online at KidKraft https://prdregistration.kidkraft.com/ 4630 Olin Road Dallas, TX 75244 United States KidKraft would like to say Thank You for Attention: Customer Service your time and feedback.
