2. Specifications

2.1.

Core System

CPU
L3 Cache
Memory
BIOS
Platform Controller Hub
2.2.

Expansion Busses

PCI Express
Other
Specifications
7th Generation Intel® Core™ and Celeron® processor SoC (formerly "Kaby Lake U")
•
Intel® Core™ i7-7600U 2.8 GHz (3.9 GHz Turbo), 15W (cTDP support) (2C/GT2)
•
Intel® Core™ i5-7300U 2.6 GHz (3.5 GHz Turbo), 15W (cTDP support) (2C/GT2)
•
Intel® Core™ i3-7100U 2.4 GHz (no Turbo), 15W (cTDP support) (2C/GT2)
•
Intel® Celeron® 3965U 2.2 GHz (no Turbo), 15W (cTDP support) (2C/GT1)
Supports: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64
Architecture, Execute Disable Bit, Intel® Turbo Boost Technology 2.0, Intel® AVX2, Intel®
AES-NI, PCLMULQDQ Instruction, Intel® Device Protection Technology with Intel®
Secure Key, Intel® TSXNI
Note: Availability of features may vary between processor SKUs.
4MB for Core™ i7, 3MB for Core™ i5 and Core™ i3, 2MB for Celeron®
Dual channel non-ECC 1866/2133 MHz DDR4 memory up to 32 GB in dual SODIMM
socket
AMI EFI with CMOS backup in 16MB SPI BIOS with Intel® AMT 11.0 support (AMT
supported on i7/i5 SKUs only)
Integrated PCH-LP
5x PCI Express x1 Gen3 (AB):
Lanes 0/1/2/3/4, supports x4, x2, x1 configuration
(up to 6x PCI Express x1 Gen3 support by build option, in place of GbE)
•
LPC bus
•
SMBus (system)
• 2
I C (user)
