3.3.4.
Gigabit Ethernet
Gigabit Ethernet
Pin
GBE0_MDI0+
A13
GBE0_MDI0-
A12
GBE0_MDI1+
A10
GBE0_MDI1-
A9
GBE0_MDI2+
A7
GBE0_MDI2-
A6
GBE0_MDI3+
A3
GBE0_MDI3-
A2
GBE0_ACT#
B2
GBE0_LINK#
A8
GBE0_LINK100#
A4
GBE0_LINK1000# A5
GBE0_CTREF
A14
3.3.5.
Serial ATA
Signal
Pin
SATA0_TX+
A16
SATA0_TX-
A17
SATA0_RX+
A19
SATA0_RX-
A20
SATA1_TX+
B16
SATA1_TX-
B17
SATA1_RX+
B19
SATA1_RX-
B20
SATA2_TX+
A22
SATA2_TX-
A23
SATA2_RX+
A25
SATA2_RX-
A26
SATA3_TX+
B22
SATA3_TX-
B23
SATA3_RX+
B25
SATA3_RX-
B26
(S)ATA_ACT#
A28
Pinouts and Signal Descriptions
Description
Gigabit Ethernet Controller 0: Media Dependent Interface
Differential Pairs 0, 1, 2, 3. The MDI can operate in 1000,
100, and 10Mbit/sec modes. Some pairs are unused in
some modes according to the following:
1000BASE-T 100BASE-TX 10BASE-T
MDI[0]+/- B1_DA+/-
MDI[1]+/- B1_DB+/-
MDI[2]+/- B1_DC+/-
MDI[3]+/- B1_DD+/-
Gigabit Ethernet Controller 0 activity indicator, active low.
Gigabit Ethernet Controller 0 link indicator, active low.
Gigabit Ethernet Controller 0 100Mbit/sec link indicator,
active low.
Gigabit Ethernet Controller 0 1000Mbit/sec link indicator,
active low.
Reference voltage for Carrier Board Ethernet channel 1
and 2 magnetics center tap. The reference voltage is
determined by the requirements of the Module PHY and
may be as low as 0V and as high as 3.3V. The reference
voltage output shall be current limited on the Module. In
the case in which the reference is shorted to ground, the
current shall be 250 mA or less.
Description
Serial ATA channel 0, Transmit Output differential pair.
Serial ATA channel 0, Receive Input differential pair.
Serial ATA channel 1, Transmit Output differential pair.
Serial ATA channel 1, Receive Input differential pair.
Serial ATA channel 2, Transmit Output differential pair.
Serial ATA channel 2, Receive Input differential pair.
Serial ATA channel 3, Transmit Output differential pair.
Serial ATA channel 3, Receive Input differential pair.
ATA (parallel and serial) or SAS activity indicator, active low.
TX+/-
TX+/-
RX+/-
RX+/-
cExpress-KL
I/O
PU/PD Comment
I/O
Twisted pair
Analog
signals for
external
transformer.
OD
3.3VSB
OD
3.3VSB
OD
3.3VSB
OD
3.3VSB
GND
No support on
min
this product
3.3V
max
I/O
PU/PD Comment
O SATA
AC coupled on
Module
I SATA
AC coupled on
Module
O SATA
AC coupled on
Module
I SATA
AC coupled on
Module
O SATA
AC coupled on
Module
I SATA
AC coupled on
Module
O SATA
Not supported
I SATA
Not supported
O 3.3V
PU
10K
3.3V
15
