ADLINK Technology cExpress-KL User Manual page 57

7.2.4.5. System Management > Flags
Feature
Flags
BMC Flags
BIOS Select
ATX/AT-Mode
Exception Code
7.2.4.6. System Management > Power Up
Feature
Power Up
Power Up watchdog
Attention: F12 disables the Power Up
Watchdog.
ECO Mode
Power-up Mode
Attention: The Power-Up Mode only
has effect, if the module is in ATX-
Mode.
7.2.4.7. System Management > LVDS Backlight
Feature
LVDS Backlight
LVDS Backlight Bright
7.2.4.8. System Management > Smart Fan
Feature
Smart Fan
CPU Smart FanTemperature Source CPU Sensor
CPU Fan Mode
PWM Level
BIOS Setup
Options Description
Info only
Read only
Read only Display the selection of current BIOS ROM.
Read only Display ATX/AT-Mode.
Read only System exception reason.
Options Description
Info only
Enabled The Power-Up Watchdog resets the system after a
certain amount of time after power-up.
Disabled
Reduces the power consumption of the system.
Disabled
Enable
Turn On: The machine starts automatically when the
Turn on
power supply is turned on.
Remain off
Remain Off: To start the machine the power button
Last State
has to be pressed.
Last State: when powered on during a power failure
the system will automatically power on when power
is restored
Options Description
Info only
255 The value range starts by 0 and ends by 255.
Options Description
Info only
Select CPU smart fan source.
System Sensor
AUTO (Smart Fan) Select CPU Fan Mode.
Fan Off
Fan On
100 Select PWM level.
cExpress-KL
51
