ADLINK Technology cExpress-KL User Manual page 34

Signal Pin
PEG_TX15+ D101
PEG_TX15- D102
PEG_LANE_RV# D54
3.4.6. Module Type Definition
Signal Pin
TYPE0# C54
TYPE1# C57
TYPE2# D57
3.4.7. Power and Ground
Signal Pin
VCC_12V C104-C109
D104-D109
GND C1, C11, C21, C31,
C41, C51, C60, C70,
C76, C80, C84, C87,
C90, C93, C96, C100,
C103, C110, D1, D11,
D21, D31, D41, D51,
D60, D67, D70, D76,
D80, D84, D87, D90,
D93, D96, D100,
D103, D110
28
Description
PCI Express Graphics lane reversal input
strap.
Pull low on the Carrier board to reverse
lane order.
Description
The TYPE pins indicate to the Carrier Board the Pin-out Type that is
implemented on the module. The pins are tied on the module to
either ground (GND) or are no-connects (NC). For Pinout Type 1,
these pins are don't care (X).
TYPE2# TYPE1# TYPE0#
X X X
NC NC NC
NC NC GND
NC GND NC
NC GND GND
GND NC NC
The Carrier Board should implement combinatorial logic that
monitors the module TYPE pins and keeps power off (e.g
deactivates the ATX_ON signal for an ATX power supply) if an
incompatible module pin-out type is detected. The Carrier Board
logic may also implement a fault indicator such as an LED.
Description
Primary power input: +12V nominal (5 ~ 20V wide
input).
All available VCC_12V pins on the connector(s)
shall be used.
Ground - DC power and signal and AC signal return
path.
All available GND connector pins shall be used and
tied to carrier board GND plane.
I/O
I 1.05V
Pinout Type 1
Pinout Type 2
Pinout Type 3 (no IDE)
Pinout Type 4 (no PCI)
Pinout Type 5 (no IDE, no PCI)
Pinout Type 6 (no IDE, no PCI)
PU/PD Comment
Not supported
I/O Comment
Type 6
I/O PU/PD Comment
P 5-20 V
P
Pinouts and Signal Descriptions
