7.3.10. Sound
Feature
Sound
HD Audio
7.3.11. Serial Port Console
Feature
Serial Port Console
COM0
Console Redirection
Console Redirection Settings
COM1
Console Redirection
Console Redirection Settings
COM2
Console Redirection
Console Redirection Settings
COM3
Console Redirection
Console Redirection Settings
7.3.11.1. Serial Port Console > Console Redirection Settings
Feature
Console Redirection Settings
Terminal Type
Bits per second
Data Bits
66
Options Description
Info only
Disabled Control Detection of the HD-Audio device.
Enabled Disabled: HDA will be unconditionally disabled.
Enabled: HDA will be unconditionally enabled.
Auto
Auto: HDA will be enabled if present, disabled
otherwise.
Options Description
Info only
Info only
Enabled Console Redirection Enable or Disable.
Disabled
Submenu
Info only
Enabled Console Redirection Enable or Disable.
Disabled
Submenu
Info only
Enabled Console Redirection Enable or Disable.
Disabled
Submenu
Info only
Enabled Console Redirection Enable or Disable.
Disabled
Submenu
Options
Info only
VT100
VT100+
VT-UTF8
ANSI
9600
19200
38400
57600
115200
7
8
Description
Emulation: ANSI: Extended ASCII char set. VT100:
ASCII char set. VT100+: Extends VT100 to support
color, function keys, etc. VT-UTF8: Uses UTF8
encoding to map Unicode chars onto 1 or more
bytes.
Selects serial port transmission speed.
Select Data Bits.
