Row A
Pin Name
USB6-
A36
USB6+
A37
USB_6_7_OC#
A38
USB4-
A39
USB4+
A40
GND (FIXED)
A41
USB2-
A42
USB2+
A43
USB_2_3_OC#
A44
USB0-
A45
USB0+
A46
VCC_RTC
A47
EXCD0_PERST#
A48
EXCD0_CPPE#
A49
LPC_SERIRQ
A50
GND (FIXED)
A51
PCIE_TX5+ *
A52
PCIE_TX5- *
A53
GPI0
A54
PCIE_TX4+
A55
PCIE_TX4-
A56
GND
A57
PCIE_TX3+
A58
PCIE_TX3-
A59
GND (FIXED)
A60
PCIE_TX2+
A61
PCIE_TX2-
A62
GPI1
A63
PCIE_TX1+
A64
PCIE_TX1-
A65
GND
A66
GPI2
A67
PCIE_TX0+
A68
PCIE_TX0-
A69
GND (FIXED)
A70
LVDS_A0+
A71
(eDP_TX2+)*
LVDS_A0-
A72
(eDP_TX2+)*
LVDS_A1+
A73
(eDP_TX1+ )*
LVDS_A1-
A74
(eDP_TX1- )*
LVDS_A2+
A75
(eDP_TX0+ )*
LVDS_A2-
A76
(eDP_TX0- )*
LVDS_VDD_EN
A77
(eDP_VDD_EN)*
LVDS_A3+
A78
LVDS_A3-
A79
10
Row B
Pin Name
USB7-
B36
USB7+
B37
USB_4_5_OC#
B38
USB5-
B39
USB5+
B40
GND (FIXED)
B41
USB3-
B42
USB3+
B43
USB_0_1_OC#
B44
USB1-
B45
USB1+
B46
EXCD1_PERST#
B47
EXCD1_CPPE#
B48
SYS_RESET#
B49
CB_RESET#
B50
GND (FIXED)
B51
PCIE_RX5+ *
B52
PCIE_RX5- *
B53
GPO1
B54
PCIE_RX4+
B55
PCIE_RX4-
B56
GPO2
B57
PCIE_RX3+
B58
PCIE_RX3-
B59
GND (FIXED)
B60
PCIE_RX2+
B61
PCIE_RX2-
B62
GPO3
B63
PCIE_RX1+
B64
PCIE_RX1-
B65
WAKE0#
B66
WAKE1#
B67
PCIE_RX0+
B68
PCIE_RX0-
B69
GND (FIXED)
B70
LVDS_B0+
B71
LVDS_B0-
B72
LVDS_B1+
B73
LVDS_B1-
B74
LVDS_B2+
B75
LVDS_B2-
B76
LVDS_B3+
B77
LVDS_B3-
B78
LVDS_BKLT_EN
B79
(eDP_BKLT_EN)*
Row C
Pin Name
DDI3_CTRLCLK_AUX+
C36
DDI3_CTRLDATA_AUX-
C37
DDI3_DDC_AUX_SEL
C38
DDI3_PAIR0+
C39
DDI3_PAIR0-
C40
GND (FIXED)
C41
DDI3_PAIR1+
C42
DDI3_PAIR1-
C43
DDI3_HPD
C44
RSVD
C45
DDI3_PAIR2+
C46
DDI3_PAIR2-
C47
RSVD
C48
DDI3_PAIR3+
C49
DDI3_PAIR3-
C50
GND (FIXED)
C51
PEG_RX0+
C52
PEG_RX0-
C53
TYPE0#
C54
PEG_RX1+
C55
PEG_RX1-
C56
TYPE1#
C57
PEG_RX2+
C58
PEG_RX2-
C59
GND (FIXED)
C60
PEG_RX3+
C61
PEG_RX3-
C62
RSVD
C63
RSVD
C64
PEG_RX4+
C65
PEG_RX4-
C66
RSVD
C67
PEG_RX5+
C68
PEG_RX5-
C69
GND (FIXED)
C70
PEG_RX6+
C71
PEG_RX6-
C72
GND
C73
PEG_RX7+
C74
PEG_RX7-
C75
GND
C76
RSVD
C77
PEG_RX8+
C78
PEG_RX8-
C79
Row D
Pin Name
DDI1_PAIR3+
D36
DDI1_PAIR3-
D37
RSVD
D38
DDI2_PAIR0+
D39
DDI2_PAIR0-
D40
GND (FIXED)
D41
DDI2_PAIR1+
D42
DDI2_PAIR1-
D43
DDI2_HPD
D44
RSVD
D45
DDI2_PAIR2+
D46
DDI2_PAIR2-
D47
RSVD
D48
DDI2_PAIR3+
D49
DDI2_PAIR3-
D50
GND (FIXED)
D51
PEG_TX0+
D52
PEG_TX0-
D53
PEG_LANE_RV#
D54
PEG_TX1+
D55
PEG_TX1-
D56
TYPE2#
D57
PEG_TX2+
D58
PEG_TX2-
D59
GND (FIXED)
D60
PEG_TX3+
D61
PEG_TX3-
D62
RSVD
D63
RSVD
D64
PEG_TX4+
D65
PEG_TX4-
D66
GND
D67
PEG_TX5+
D68
PEG_TX5-
D69
GND (FIXED)
D70
PEG_TX6+
D71
PEG_TX6-
D72
GND
D73
PEG_TX7+
D74
PEG_TX7-
D75
GND
D76
RSVD
D77
PEG_TX8+
D78
PEG_TX8-
D79
