Feature
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Putty KeyPad
Redirection After BIOS Post
7.3.11.2. Serial Port Console >Legacy Console Redirection Settings
Feature
Legacy Serial Redirection Port
7.3.11.3. Serial Port Console >Console Redirection Settings
Feature
Out-of-Band Mgmt Port
Terminal
BIOS Setup
Options Description
Select Parity.
None
Even
Odd
Mark
Space
Select number of stop bits.
1
2
Select flow control.
None
Hardware RTS/CTS
Disabled Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals.
Enable
With this mode enabled only text will be sent. This is
Disabled
to capture Terminal data.
Enable
Enables or disables extended terminal resolution
Disabled
Enable
On Legacy OS, the Number of Rows and Columns
80x24
supported redirection
80x25
Select FunctionKey and KeyPad on Putty.
VT100
LINUX
XTERMR6
SCO
ESCN
VT400
The Settings specify if BootLoader is selected than
Always Enabled
Legacy console redirection is disabled before
BootLoader
booting to Legacy OS. Default value is Always
Enable which means Legaacy console Redirection is
enabled for Legacy OS.
Options Description
Select a COM port to display redirection of Legacy
COM0
OS and Legacy OPROM Messages.
COM1
COM2
COM3
Options Description
Microsoft Windows Emergency Management
COM0
Services (EMS) allows for remote management of a
COM1
Windows Server OS through a serial port.
COM2
COM3
VT100
VT100+
VT-UTF8
ANSI
