7.3.14. Miscellaneous
Feature
Trusted Computing
NVME Configuration
7.3.14.1. Miscellaneous > Trusted Computing
Feature
Security Device Support
7.3.14.2. Miscellaneous > Trusted Computing (Enable Security Device Support and TPM device found)
Feature
Security Device Support
Active PCR banks
Available PCR banks
SHA-1 PCR Bank
SHA256 PCR Bank
Pending Operation
Platform Hierarchy
Storage Hierarchy
Endorsement Hierarchy
TPM2.0 UEFI Spec Version
Physical Presence Spec Version
TPM 20 InterfaceType
Device Select
BIOS Setup
Options Description
Submenu
Submenu
Options
Enabled
Disabled
Options
Enabled
Disabled
Info only
Info only
Enabled
Disabled
Enabled
Disabled
None
TPM clear
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
TCG_2
TCG_1_2
1.2
1.3
Info only
TPM 1.2
TPM 2.0
Auto
Description
Enables or Disables BIOS support for security
device. When disabled OS wil not show Security
Device. TCG EFI protocol and INT1A interface will
not be available
Description
Enables or Disables BIOS support for security
device. When disabled OS wil not show Security
Device. TCG EFI protocol and INT1A interface will
not be available
Enable or Disable SHA-1 PCR Bank
Enable or Disable SHA256 PCR Bank
Schedule an operation for the Security Device. Note:
Your Computer will reboot during restart in order to
change State of Security Device.
Enable or Disable Platform Hierarchy
Enable or Disable Storage Hierarchy
Enable or Disable Endorsement Hierarchy
Select the TCG2 Spec Version Support.
TCG_1_2: Compatible mode for Win8/Win10:
TCG_2: Supports new TCG2 protocol and event
format for Win10 or later
Select to tell O.S. to support PPI Spec Version 1.2 or
1.3. Note some HCK tests might not support 1.3.
TPM 1.2 will restrict support to TPM 1.2 devices,
TPM 2.0 will restrict support to TPM 2.0 devices,
Auto will support both with the default set to TPM 2.0
devices if not found, TPM 1.2 devices will be
enumerated
