6.6.

PCI Interrupt Routing Map

INT P.E.G. Root
Line Port
Int0 INTA:16
Int1 INTB:17
Int2 INTC:18
Int3 INTD:19
INT GbE
Line Controller
Int0 INTA:16
Int1
Int2
Int3
INT LPC SATA
Line Controller Controller #1
Int0 INTA:16 INTA:16
Int1 INTB:17
Int2 INTC:18
Int3 INTD:19
6.7.

SMBus Address Table

Device Address
DIMM A A0h
DIMM B A4h
BMC 50h
Extend GPIO 40h
NXP(eDP to LVDS C0h
transmitter)
46
Audio xHCI Controller
Controller
INTA:16 INTA:16
HDA PCIE port1
Controller
INTA:16
INTB:17
INTC:18
INTD:19
SMBus
Controller
INTA:16
ME Controller ME Controller
#1 #2
INTA:16
INTD:17
INTC:18
INTB:19
PCIE port 2 PCIE port 3
INTB:17 INTC:18
INTC:18 INTD:19
INTD:19 INTA:16
INTA:16 INTB:17
SATA
Controller #2
IDE-R KT
PCIE port 4 PCIE port5
INTD:19 INTA:16
INTA:16 INTB:17
INTB:17 INTC:18
INTC:18 INTC:19
System Resources
