ADLINK Technology COM Express CEI-4x10GBASE-T User Manual

Network adapter card for express-id7
Hide thumbs

Advertisement

Quick Links

Download this manual
CEI-4x10GBASE-T Network Adapter
CEI-4x10GBASE-T
Network Adapter Card for Express-ID7
Page 1
Revision:
0.1
Date:
2023-12-19
Part Number:
50M-79022-1000
Copyright © 2023 ADLINK Technology, Inc.
User's Guide
PICMG COM.0 R3.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the COM Express CEI-4x10GBASE-T and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology COM Express CEI-4x10GBASE-T

Summary of Contents for ADLINK Technology COM Express CEI-4x10GBASE-T

  • Page 1 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 CEI-4x10GBASE-T User’s Guide Network Adapter Card for Express-ID7 Revision: Date: 2023-12-19 Part Number: 50M-79022-1000 Page 1 Copyright © 2023 ADLINK Technology, Inc.
  • Page 2 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 Revision History Revision Description Date Author Preliminary release 2023-12-19 Page 2 Copyright © 2023 ADLINK Technology, Inc.
  • Page 3 Product names mentioned herein are used for identification purposes only and may be trademarks / registered trademarks of respective companies. Copyright © 2023 ADLINK Technology Incorporated This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Only install/attach and operate equipment on stable surfaces and/or recommended mountings; • If the equipment will not be used for long periods of time, turn off the power source and unplug the equipment. • Page 4 Copyright © 2023 ADLINK Technology, Inc.
  • Page 5 Caution: This information indicates the possibility of minor physical injury, component damage, data loss, and/or program corruption. Warning: This information warns of possible serious physical injury, component damage, data loss, and/or program corruption. Page 5 Copyright © 2023 ADLINK Technology, Inc.
  • Page 6 ADLINK Technology GmbH Hans-Thoma-Strasse 11, D-68163 Mannheim, Germany Tel: +49-621-43214-0 Fax: +49-621 43214-30 Email: emea@adlinktech.com Please visit the Contact page at www.adlinktech.com for information on how to contact the ADLINK regional office nearest you. Page 6 Copyright © 2023 ADLINK Technology, Inc.
  • Page 7 4.1. Input Interface Definitions ............................................................14 5. Module Interfaces and Configuration ..................................................... 17 5.1. Connector and LED Locations ..........................................................17 5.2. LED Indicators ................................................................18 5.3. 10GbE Adaptor Card Installation ..........................................................19 6. Mechanical ..............................................................20 Page 7 Copyright © 2023 ADLINK Technology, Inc.
  • Page 8 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 List of Figures Figure 1 – CEI-4x10GBASE-T function diagram .................................................. 13 Figure 2 – Adapter card feature locations .................................................... 17 Figure 3 – CEI-4x10GBASE-T mechanical dimensions ..............................................20 Page 8 Copyright © 2023 ADLINK Technology, Inc.
  • Page 9 Utilizing the CEI-4x10GBASE-T card along with an Express-ID7 module and Express-BASE7 reference carrier board, you can quickly emulate the functionality of your end product for software development and hardware verification. Applications include entry level switch, cloud storage platforms, communications servers, and more. Page 9 Copyright © 2023 ADLINK Technology, Inc.
  • Page 10 Dedicated ROM for storing PHY firmware ID EEPROM (AT24CS32 EEPROM) I2C-based device, identifies the capabilities of the attached site. This allows the firmware to configure the attached PHY(s) and necessary I/O modes. Page 10 Copyright © 2023 ADLINK Technology, Inc.
  • Page 11 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 2.3. Dimensions 168 mm x 107 mm (PCB only, including edge connector) 2.4. Operating Temperature 0°C to 55°C Page 11 Copyright © 2023 ADLINK Technology, Inc.
  • Page 12 Additional expander and EEPROM not mentioned are described below: PCA9575 IO Expander I2C-based device, de-serialized for low speed sideband IO, including interrupt, reset, etc. PCA9685 LED Ctrl I2C-based device, controls LED indication Page 12 Copyright © 2023 ADLINK Technology, Inc.
  • Page 13 (4 ports) CEI_MDIO/MDC RST, INT CEI_I2C (SDA/SCL) PCA9685 LED indicators LED Ctrl Link Status CEI_RST# Link Speeds CEI_INT# AT24CS32 ID EEPROM PCA9575 WP etc... IO Expander CEI_PRSNT# Figure 1 – CEI-4x10GBASE-T function diagram Page 13 Copyright © 2023 ADLINK Technology, Inc.
  • Page 14 PICMG COM.0 R3.1 specification. Signals described in the specification but not supported on the CEI-4x10GBASE-T card are marked with strikethrough STRIKETHROUGH. Row B Row A Name Name CEI_SDA CEI_SCL 3V3SB (TBC) 3V3SB (TBC) CB_RST-L (TBC) Page 14 Copyright © 2023 ADLINK Technology, Inc.
  • Page 15 Name Name CEI_INT# 10G_KR_RX3+ 10G_KR_RX3- 10G_KR_TX3+ 10G_KR_TX3- 10G_KR_RX2+ 10G_KR_RX2- 10G_KR_TX2+ 10G_PHY_RST_01 (TBC) 10G_KR_TX2- CEI_RST# CEI_SDA (TBC) 10G_KR_RX1+ CEI_SCL (TBC) 10G_KR_RX1- 10G_KR_TX1+ 10G_KR_TX1- CEI_MDIO CEI_MDC 10G_KR_RX0+ 10G_KR_RX0- 10G_KR_TX0+ 10G_KR_TX0- 10G_SDP3 10G_SDP2 10G_SDP1 CEI_PRSNT# Page 15 Copyright © 2023 ADLINK Technology, Inc.
  • Page 16 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 Row B Row A Name Name 10G_SDP0 Page 16 Copyright © 2023 ADLINK Technology, Inc.
  • Page 17 5. Module Interfaces and Configuration This chapter describes connectors, LEDs, and switches that are used on the CEI-4x10GBASE-T adapter card. 5.1. Connector and LED Locations Figure 2 – Adapter card feature locations Page 17 Copyright © 2023 ADLINK Technology, Inc.
  • Page 18 Green / Yellow Yellow 1 Gbps link speed Green 10 Gbps link speed Link / Active Green No Link Status Steady On Link established, no activity detected Blinking Link established, activity detected Page 18 Copyright © 2023 ADLINK Technology, Inc.
  • Page 19 Below is an example (illustration purposes only) of a CEI-4x10GBASE-T adapter card installed on an Express-BASE7 carrier board with a Type 7 Express- ID7 module. Note: If input 5VSB-to-10GbE adapter card is needed for testing purposes, a specific cable and connection are required. Please contact an ADLINK representative for details. Page 19 Copyright © 2023 ADLINK Technology, Inc.
  • Page 20 CEI-4x10GBASE-T Network Adapter PICMG COM.0 R3.1 6. Mechanical Figure 3 – CEI-4x10GBASE-T mechanical dimensions Note: All dimensions are shown in millimeters with a tolerances of ± 0.25mm unless otherwise noted. Page 20 Copyright © 2023 ADLINK Technology, Inc.
