ADLINK Technology cExpress-KL User Manual page 74

Feature
Bits per second
Flow Control
Data Bits
Parity
Stop Bits
7.3.12. ICC Configuration
Feature
ICC Information
ICC PLL Shutdown
Note: The item only available in the standard BIOS .These options can be made available by customer
request if neccessary.
7.3.13. Thermal
Feature
Thermal
Active Trip Point
Passive Trip Point
Critical Trip Point
Watchdog ACPI Even Shutdown
68
Options
9600
19200
38400
57600
115200
None
Hardware RTS/CTS
Software Xon/Xoff
Info only
Info only
Info only
Options
Info only
Disabled
Enabled
Options
Info only
Disabled
40 C
50 C
60 C
70 C
BMC Default
Disabled
80 C
90 C
Disabled
65 C
75 C
85 C
Disabled
Enable
Description
Selects serial port transmission speed.
The speed must be matched on the other side. Long
or noisy lines may require lower speeds.
Flow control can prevent data loss from buffer
overflow. When sending data, if the receiving buffers
are full, a 'stop' signal can be sent to stop the data
flow. Once the buffers are empty, a 'start' signal can
be sent to re-start the flow. Hardware flow control
uses two wires to send start/stop signals.
Description
This option controls the programming of the ICC PLL
shutdown flow. When enabled, this ICC PM register will
be programmed on every non-Sx boot.
Description
This value controls the temperature of the ACPI Active
Trip Point - the point in which the OS will turn the
processor fan on Active Trip Point Fan Speed.
This value controls the temperature of the ACPI Passive
Trip Point - the point in which the OS will begin throttling
the processor.
This value is the temperature threshold of the Critical
Trip Point.
Watchdog ACPI Even Shutdown Enable/Disable.
BIOS Setup
