2.3.

Video

Integrated on Processor
GPU Feature Support
Display Types
2.4.

Audio

Integrated
Codec
2.5.

LAN

Integrated
Intel PHY
Interface
2.6.

Multi I/O and Storage

I/O Hub
USB
SATA
GPIO
4
Intel® Generation 9 Low Power Graphics core architecture (Intel® HD Graphics 620/610)
•
3 independent and simultaneous display combinations of DisplayPort/HDMI/LVDS/VGA
monitors (eDP & VGA by build option, support by project basis)
•
Encode/transcode HD content
•
Playback of high definition content including Blu-ray Disc
•
Playback of Blu-ray disc S3D content using HDMI (1.4a spec compliant with 3D)
•
DirectX Video Acceleration (DXVA2) support for accelerated video processing
•
AVC/VC1/MPEG2/HEVC/VP8/JPEG HW decode
•
AVC/MPEG2/HEVC/VP8/JPEG HW encode
•
Advanced Scheduler 2.0, 1.0, XPDM support
•
DirectX 11.3, OpenGL 4.4, OpenGL ES 2.0 and OpenCL 2.0
•
Multi Display Support: 3 independent displays
Note: Availability of features may vary between processor SKUs.
•
Single/dual channel 18/24-bit LVDS via eDP-to-LVDS chip, supports DE mode and H/V-
Sync mode display. Resolution up to 1920x1200 with dual channel LVDS.
(eDP 4 lanes available as build option in place of LVDS)
•
2x Digital Display Ports:
DDI1 supports DisplayPort/HDMI/DVI
DDI2 supports DisplayPort/HDMI/DVI
•
VGA (build option) via DP-to-VGA chip. Resolution up to 1920x1200. in place of DDI 2
Note: Supports HDMI 1.4, DP 1.2 and eDP 1.3.
Intel® HD Audio integrated on SoC
Located on carrier Express-BASE6 (ALC886 standard support)
MAC integrated on SoC
Intel® Ethernet Controller I219-LM or I219-V (only LM version support iAMT)
10/100/1000 Mbit/s connection
Integrated on SoC
4x USB 3.0 ports (USB0,1,2,3) and 4x USB 2.0 ports (USB4,5,6,7)
All USB support by XHCI controller.
3x SATA 6Gb/s ports, RAID 0/1/5 support
4 GPO and 4 GPI, GPI with interrupt
Specifications
