Feature
Hsync Polarity
LVDS Backlight Mode
GTT LVDS/eDP Backlight Control
DDI port 1
DDI port 2
Primary IGFX Boot Display
LCD Panel Type
eDP/LVDS
Panel Scaling
BIOS Setup
Options Description
Hsync Polarity select
Active High
Active Low
Select LVDS Backlight control function.
BMC Mode
GTT Mode
255 Set VBIOS Brightness.
Range::0-255.
No device Select DDI port 1 function: DisplayPort or HDMI.
Display Port
HDMI
DisplayPort with
HDMI/DVI Compatible
No device Select DDI port 2 function: DisplayPort or HDMI.
Display Port
HDMI
DisplayPort with
HDMI/DVI Compatible
Select the Video Device which will be activated during
VBIOS Default
POST.This has no effect if external graphics present.
Secondary boot display selection will appear based on
your selection. VGA modes will be supported only on
primary display.
Select LCD panel used by Internal Graphics Device by
VBIOS Default
selecting the appropriate setup item.
640X480
800X600
1024X768
1280X1024
1400X1050 LVDS1
1400x1050 LVDS2
1600X1200
1366X768
1680X1050
1920X1200
1440X900
1600X900
1024X768
1280X800
1920X1080
2048X1536
Enable/Disable eDP/LVDS.
Disable
Enable
Select the LCD panel scaling option used by the Internal
Auto
Graphics Device.
Off
Force Scaling
