XDP Debug Header

The debug port is a connection into a target-system environment that provides access to JTAG, run control, system
control, and observation resources. The XDP target system connector is a Samtec™ 60-pin BSH-030-01 series
connector.
Pin XDP Signal Target Signal
1 GND GND
3 OBSFN_A0 PREQ#
5 OBSFN_A1 PRDY#
7 GND GND
9 OBSDATA_A0 CFG[0]
11 OBSDATA_A1 CFG[1]
13 GND GND
15 OBSDATA_A2 CFG[2]
17 OBSDATA_A3 CFG[3]
19 GND GND
21 OBSFN_B0 BPM#[0]
23 OBSFN_B1 BPM#[1]
25 GND GND
27 OBSDATA_B0 CFG[4]
29 OBSDATA_B1 CFG[5]
31 GND GND
33 OBSDATA_B2 CFG[6]
35 OBSDATA_B3 CFG[7]
37 GND GND
39 HOOK0 PWRGOOD
41 HOOK11 BP_PWRGD_RST#
43 VCC_OBS_AB VCCIO_OUT
45 HOOK2 PWR_DEBUG
47 HOOK3 PCH_SYS_PWROK
49 GND GND
51 SDA1 SDA
53 SCL1 SCL
55 TCK1 Open
57 TCK0 TCK
59 GND GND
Notes:
1. These signals are optional, can be left as OPEN/No-Connect if debug by Intel will not be needed.
2. These CFG signals can be left as Open/No Connect if not used as a strapping signal and top side probe
will be used to debug processor.
Refer to the "Shark Bay, Denlow and Broadwell U/Y Platforms Debug Port Design Guide", Document Number: 479493, Revision: 2.0
32
I/O Device
NA
I/O Processor
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
1
I/O Processor
1
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
I System
O System
I System
O Processor
O System
NA
I/O System
I/O System
NA
O Processor
NA
Table 4: XDP Debug Header Pin Definition
Pin XDP Signal Target Signal
2 GND GND
4 OBSFN_C0 CFG[17]
6 OBSFN_C1 CFG[16]
8 GND GND
10 OBSDATA_C0 CFG[8]
12 OBSDATA_C1 CFG[9]
14 GND GND
16 OBSDATA_C2 CFG[10]
18 OBSDATA_C3 CFG[11]
20 GND GND
22 OBSFN_D0 CFG[19]
24 OBSFN_D1 CFG[18]
26 GND GND
28 OBSDATA_D0 CFG[12]
30 OBSDATA_D1 CFG[13]
32 GND GND
34 OBSDATA_D2 CFG[14]
36 OBSDATA_D3 CFG[15]
38 GND GND
40 ITPCLK/HOOK4 Open
42 ITPCLK#/HOOK5 Open
44 VCC_OBS_CD VCCIO_OUT
46 HOOK6/RESET# PLTRSTIN#
48 HOOK7/DBR# DBR#
50 GND GND
52 TDO TDO
54 TRSTn TRST#
56 TDI TDI
58 TMS TMS
60 GND GND (or
XDP_PRESENT#
if required)
I/O Device
NA
2
I Processor
2
I Processor
NA
2
I/O Processor
2
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
2
I/O Processor
2
I/O Processor
NA
2
I Processor
2
I Processor
NA
2
I/O Processor
2
I/O Processor
NA
NA
NA
I System
I System
O System
NA
I Processor
O Processor
O Processor
O Processor
NA
Connector Pinouts on Module
