2.3.

Video

Integrated on Processor
GPU Feature Support
Multi Display Support
Display Interface Support
2.4.

Audio

Integrated
Codec
2.5.

LAN

Integrated
Intel PHY
Interface
2.6.

Multi I/O and Storage

Integrated
USB
SATA*
PATA
GPIO
*Note: Fourth SATA port (SATA 3) supported by build option in place of PATA
4
Intel® Generation 9 Graphics core architecture
•
2 independent and simultaneous display combinations of VGA / LVDS monitors
•
Encode/transcode HD content
•
Playback of Blu-ray Disc 3D content using HDMI (1.4a spec compliant with 3D)
•
DirectX Video Acceleration (DXVA) support for accelerated video processing
•
HEVC/H.265, H.264, M/JPEG, MPEG2, VC1, WMV9, VP8/VP9 HW decode
•
HEVC/H.265, M/JPEG, MPEG2 HW encode
•
Advanced Scheduler 2.0, 1.0, XPDM support
•
DirectX 12, DirectX 11.3, DirectX 11, DirectX 10.1, DirectX 10, DirectX 9 suppor
•
OpenGL up to 4.4, OpenCL up to 2.1 support
Note: Availability of features s dependent on OS (Win 10/8.1/7, Linux, VxWorks)
2 independent displays
•
VGA Interface support through DP-to-VGA chip
•
LVDS Interface single/dual channel 18/24-bit LVDS through eDP-to-LVDS chip;
supports DE mode and Hsync/Vsync mode; max. resolution 1920x1200 @60Hz in dual
mode; pixel clock frequency up to 112MHz; VESA and JEIDA panel data formats
supported
•
Digital Display Interface support in place of PEG lanes (by build option, max. two DDI
channels)
Intel® HD Audio integrated in QM175/HM175/CM238 Chipset
Located on Express-BASE carrier (Realtek ALC886)
MAC integrated in QM175/HM175/CM238 Chipset
Intel® Ethernet Connection I219LM or I219V (only LM supports Intel® AMT)
10/100/1000 Mbit/s GbE connection
Intel® QM175/HM175/CM238 Chipset
8x USB 2.0 (USB 0-7)
3x SATA 6Gb/s (SATA 0-2)
1x PATA IDE (via SATA-to-PATA bridge), Master only
4 GPO and 4 GPI with interrupt
