2.3.

Video

Integrated on Processor
GPU Feature Support
Display Interface Support
2.4.

Audio

Integrated
Codec
2.5.

LAN

Integrated
Intel PHY
Interface
2.6.

Multi I/O and Storage

Integrated
USB
SATA*
GPIO
*Note: For SATA 6Gb/s compatibility, it is strongly recommended to use a SATA redriver on the carrier board.
4
Intel® Generation 9 Graphics core architecture
•
3 independent and simultaneous combinations of DisplayPort/HDMI/LVDS graphics
outputs (eDP optional in place of LVDS)
•
Encode/transcode HD content
•
Playback of high definition content including Blu-ray Disc
•
Playback of Blu-ray Disc 3D content using HDMI (1.4a spec compliant with 3D)
•
DirectX Video Acceleration (DXVA) support for accelerated video processing
•
HEVC/H.265 10-bit, H.264, M/JPEG, MPEG2, VC1, WMV9, VP9 10-bit HW decode
•
HEVC/H.265 10-bit, M/JPEG, MPEG2 HW encode
•
Advanced Scheduler 2.0, 1.0, XPDM support
•
DirectX 12, DirectX 11.3, DirectX 11, DirectX 10.1, DirectX 10, DirectX 9 support
•
OpenGL up to 4.4, OpenCL up to 2.1 support
•
High Dynamic Range (HDR) Rec. 2020 support
Note: Availability of features s dependent on operating system (Windows 10 64-bit, Linux
64-bit, VxWorks 7)
•
LVDS: single/dual channel 18/24-bit LVDS through eDP to LVDS, supports DE mode
and Hsync/Vsync mode
•
eDP: eDP 1.4 up to 4 lane support, in place of LVDS (BOM option)
•
Digital Display Ports x3: DDI1/2/3 support DisplayPort/HDMI/DVI
Intel® HD Audio integrated in QM175/HM175/CM238 Chipset
Located on carrier Express-BASE6 (ALC886 standard support)
MAC integrated in QM175/HM175/CM238 Chipset
Intel® Ethernet Controller I219-LM or I219-V
10/100/1000 Mbit/s connection
Intel® QM175/HM175/CM238 Chipset
4x USB 3.0 (USB 0,1,2,3), 4x USB 2.0 (USB 4,5,6,7)
4x SATA 6Gb/s (SATA 0,1,2,3)
4 GPO and 4 GPI
Specifications
