10.2 Data logger

When a MM card is inserted into the instrument, a data logger recording can be performed.
The measured values are stored one after the other on the MM card depending on the
recording interval set and are merged into a file with the format * .csv.
The measured values can be evaluated using MS Excel or open office CALC.
Hint
The data logger is ONLY available when a MM card is inserted into the
instrument.
The following adjustments are available in the Data processing / Data logger menu:
Parameter
Data logger
Save to MMC
CSV-Header
If the data logger becomes active or becomes active again after an interruption, a new file is
created on the MM card, in which all subsequent measured values of the recording are
saved. The files have a predefined name and are numbered consecutively.
Hint
Each measurement is assigned its own file with collected measured values. Each
file is automatically named and numbered.
ecom-EN3
To use the data logger, insert a MM card into the instrument.
Meaning
Start, Stop Data logger
Adjustment of the interval time
for data logger recordings
Adjustment of data logging with
or without column headings
To select the correct data logger file use the date identification:
J2KDL-00.csv -- oldest file
J2KDL-01.csv
J2KDL-02.csv
J2KDL-XX.csv -- newest file
Adjustment
Yes, No
1 ... 999 s
On, Off
Factory setting
No
1 s
Off
