12. Data Processing
12.1. Communication
If a MM card is inserted in the slot, so it
will be used as record medium. The
menu „Data processing" offers the
following functions:
Select:
For search or creation of plants files for measurement values as-
signment (compare chapter 7.).
View:
Recorded values to a selected plant can be viewed
(compare chapter 7.).
Memory (M):
Here all stored measurements (sorted
by record number) can be seen. Indi-
vidual measurement values can be
called as follows:
-Choose record number with the cursor
keys and confirm with <OK>
-Scroll with the cursor keys
-Leave record number with <ESC>
DRT <-> PC !:
Load data:
Enables the data import from e.g. rbr
software (available on our website
„www.rbr.de"). See chapter „Technical
Data" for data
(please observe the transfer options of
your software!).
Page 34
format information
Select
View
Memory (M)
DRT <-> PC !
Format
Quit with:
Automatic measu.
Date Time
1 01.09.06 11:01:24
2 01.09.06 11:02:34
3 01.09.06 11:04:20
4 01.09.06 11:07:44
5 01.09.06 11:11:25
6 01.09.06 11:23:02
7 01.09.06 11:44:09
8 01.09.06 11:53:13
9 01.09.06 11:59:59
10 01.09.06 11:59:59
↑↓ ↑↓
↑↓ ↑↓
Select:
DRT <-> PC !
Send dada
Load data
Quit with:
ecom-J2KN
Fuel type
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
Fuel oil
