4. Data processing

4.1. Data storage

The measurements made with the equipment can be assigned to a customer. For
each customer a file with file name is created on the memory card (e.g.:
DP3_0001.DAT). Into this file all measurements belonging to the customer are
written.
The files can be transferred to the PC using a card reader. With the software
"DP3Report" a protocol for each check can be made. The following conditions
must be fulfilled for using a multi media card:
- min. card volume 32 MB - max.32 GB (UHC)
- card formatted on 16 bit FAT or FAT32
- SD cards from SanDisk recommended
- PC with card reader
Never pull out cards during data record - data loss and damaging

4.2. Edit customer

If the instrument gets switched on and a SD or MM
Card with no customer data is inserted the inquiry
follows whether you would like to edit a customer. If
the measurement is to be assigned to a customer,
press the key <F1> (<F4> = no: Measurement is
made without allocation). Proceed as follows:
-select line to be filled out with the cursor keys
<up/down> and confirm with <Enter>
-select keyboard <F3>
(4 keyboard are available)
-select a character with the cursor keys
<up/down/right/left>
(selected character is black deposited)
-take over the character with <Enter> (the last
character can be deleted with <F2>)
-repeat the procedure, until the desired designation
is complete
-if a character is to be corrected, proceeded as
follows:
-interrupt the character selection with <F4>
ecom-DP3
of the data carrier possible!
No customer
existing!
Create new
YES NO
Customer number
Name
Street
ZIP/City
DP3_0001.DAT
Tel.
Others
